QFX5200 Chassis Status LEDs

14
The QFX5200 switch series has four status LEDs on the FRU side of the chassis, next to
the management ports (see

Figure 6: Chassis Status LEDs on a QFX5200 Switch

1— Status LEDs
2— em0–RJ-45 (10/100/1000 Base-T)
management Ethernet port (C0)
3—RJ-45 console port (C0N) )
Table 10 on page 15 describes the chassis status LEDs on a QFX5200 switch, their colors
and states, and the status they indicate. You can view the colors of the three LEDs
remotely through the CLI by issuing the operational mode command
Figure 6 on page 14).
4— USB port
5— em1–SFP management Ethernet port (C1)
Cage (socket for either 10/100/1000 Base-T
RJ45 SFP or 1GbE fiber SFP)
show chassis lcd
