QFX5210 Quick Start Guide
IN THIS GUIDE
Mounting and Connecting Power to the Switch | 1
Mounting and Connecting Power to the Switch
IN THIS SECTION
Before You Start | 1
Mount The Switch | 2
Before You Start
The QFX5210-64C is available in AC and DC power models. Mount QFX5210-64C models only in a four-post rack. This
procedure describes the installation into a four-post rack and connecting AC power. For DC connection procedures, see
the complete QFX5210 hardware documentation at
To install a Juniper Networks QFX5210, you need:
Electrostatic discharge (ESD) grounding strap (not provided)
One pair of mounting rails (provided)
One pair of mounting blades (provided)
Eight screws to secure the chassis and mounting blades to the rack (not provided)
https://www.juniper.net/documentation/
.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Juniper QFX5210
Summary of Contents for Juniper QFX5210
-
Page 1: Quick Start Guide
Mount the Switch | 2 Before You Start The QFX5210-64C is available in AC and DC power models. Mount QFX5210-64C models only in a four-post rack. This procedure describes the installation into a four-post rack and connecting AC power. For DC connection procedures, see the complete QFX5210 hardware documentation at https://www.juniper.net/documentation/... -
Page 2: Mount The Switch
If you are mounting multiple units in the rack, mount the heaviest device at the bottom and mount the others from bottom to top in order of decreasing weight. The QFX5210-64C weighs approximately 31.09 lb (14.1 kg) with power supplies and fans installed. Installing these devices in a rack or cabinet requires two people to lift the switch and secure it to the rack. - Page 3 6. Repeat steps on the opposite side of the device. 7. Have one person grasp both sides of the unit, lift it, and position it in the rack so that the mounting rail is aligned with the rack holes. 8. Have a second person secure the front of the device to the rack using four mounting screws (and cage nuts and washers if your rack requires them).
- Page 4 (HTTP), or Trivial File Transfer Protocol (TFTP) server on which the software image and configuration files are stored. For more information about using ZTP for provisioning the device, see Understanding Zero Touch Provisioning. Before you begin connecting and configuring a QFX5210, set the following parameter values on the console server or Baud Rate—9600 Flow Control—None Data—8 Parity—None...
- Page 5 [edit] root@# set system services telnet NOTE: When Telnet is enabled, you cannot log in to a QFX5210 switch through Telnet using root credentials. Root login is allowed only for SSH access. 11. Enable SSH service for root login. [edit] root@# set system services SSH 12.
- Page 6 Safety Warnings Summary This is a summary of safety warnings. For a complete list of warnings, including translations, see the hardware documentation at https://www.juniper.net/documentation/. WARNING: Failure to observe these safety warnings can result in personal injury or death. Permit only trained and qualified personnel to install or replace device components.
- Page 7 For technical support, see https://www.juniper.net/support/requesting-support.html. Juniper Networks, the Juniper Networks logo, Juniper, and Junos are registered trademarks of Juniper Networks, Inc. in the United States and other countries. All other trademarks, service marks, registered marks, or registered service marks are the property of their respective owners.
