QFX5200 Switch Hardware Guide

Unpacking a QFX5200

Table 30: Inventory of Components Supplied with a QFX5200 Device

Component
Chassis with five fan modules and two power supplies.
Rear mounting blades
Front mounting brackets
Extension brackets
RJ-45 cable and RJ-45 to DB-9 adapter
Related
Documentation
58
The QFX5200 switch chassis is a rigid sheet-metal structure that houses the hardware
components. A QFX5200 is shipped in a cardboard carton, secured with foam packing
material. The carton also contains an accessory box and quick start instructions.
CAUTION: The QFX5200 is maximally protected inside the shipping carton.
Do not unpack the switch until you are ready to begin installation.
To unpack a QFX5200:
Move the shipping carton to a staging area as close to the installation site as possible,
1.
but where you have enough room to remove the system components.
Position the carton so that the arrows are pointing up.
2.
Open the top flaps on the shipping carton.
3.
Remove the accessory box and verify the contents against the inventory included in
4.
the box. Table 30 on page 58
QFX5200.
Pull out the packing material holding the switch in place.
5.
Verify the chassis components received:
6.
Two power supplies
Five fan modules
Save the shipping carton and packing materials in case you need to move or ship the
7.
switch later.
Mounting a QFX5200 in a Rack or Cabinet on page 59
Installing and Connecting a QFX5200 on page 57
lists the inventory of components supplied with a
Quantity
1
2
2
2
1
