QFX5200 Switch Hardware Guide
66
CAUTION: Before you connect power to the switch, a licensed electrician
must attach a cable lug to the grounding and power cables that you supply.
A cable with an incorrectly attached lug can damage the switch (for
example, by causing a short circuit).
To meet safety and electromagnetic interference (EMI) requirements and
to ensure proper operation, you must connect the chassis to earth ground
before you connect it to power. For installations that require a separate
grounding conductor to the chassis, use the protective earthing terminal
on the switch chassis to connect to the earth ground. For instructions on
connecting earth ground, see
on page 64. The switch gains additional grounding when you plug the power
supply in the switch into a grounded AC power outlet by using the AC power
cord appropriate for your geographical location (see
Supply" on page
Install the power supply in the chassis. For instructions on installing a power supply in
a QFX5200, see "Installing a Power Supply in a QFX5200" on page
NOTE: Each power supply must be connected to a dedicated power source
outlet.
To connect AC power to a QFX5200:
Attach the grounding strap to your bare wrist and to a site ESD point.
1.
Ensure that the power supplies are fully inserted in the chassis and the latches are
2.
secure. If only one power supply is installed, ensure a that blank cover panel is installed
over the second power supply slot.
Locate the power cord or cords shipped with the switch; the cords have plugs
3.
appropriate for your geographical location. See
QFX Series Device" on page
WARNING: Ensure that the power cord does not block access to device
components or drape where people can trip on it.
Connect each power supply to the power sources. Insert the coupler end of the power
4.
cord into the AC power cord inlet on the AC power supply faceplate.
Push the power cord retainer onto the power cord (see
5.
"Connecting Earth Ground to a QFX5200"
23).
"AC Power Cord Specifications for a
39.
Copyright © 2017, Juniper Networks, Inc.
"QFX5200 AC Power
85.
Figure 22 on page 67).
