CHAPTER 1

System Overview

QFX5200 Hardware Overview

QFX5200-32C Hardware

Copyright © 2017, Juniper Networks, Inc.
QFX5200 Hardware Overview on page 3
QFX5200 Hardware Models on page 4
Understanding Hardware Redundancy of QFX5200 Components and
Functionality on page 5
The QFX5200-32C is a highly-flexible, 32-port, fixed-configuration switch that can be
configured for 10/25/40/50/100 Gigabit Ethernet speeds. The QFX5200-32C provide
100 Gbps spine and leaf connectivity in Layer 3 fabrics for cloud and web services.
This topic covers:
QFX5200-32C Hardware on page 3
System Software on page 4
The QFX5200-32C is a compact 1 U standalone switch that provides a line rate
configuration packet performance, very low latency, and a rich set of Layer 3 features.
The routing engine and control plane are driven by the 1.8 Ghz quad-core Intel CPU with
16 GB of memory and two 32 GB solid-state drives (SSD) for storage.
As shown in Figure 1 on page
switch that supports both quad small form-factor pluggable (QSFP+) and 100-Gbps
QSFP+ (QSFP28) transceivers in the 32 QSFP28 sockets. The ports
configured as either uplinks or as access ports. The QSFP28 ports are configured as
100-Gigabit Ethernet ports by default, but can also be configured to speeds of 50, 40,
25, or 10-Gigabit Ethernet.
The QFX5200-32C comes standard with redundant fans and redundant power supplies.
The switch can be ordered with either ports-to-FRUs or FRUs-to-ports airflow and with
AC or DC power supplies.
4, the QFX5200-32C is a 100 Gigabit Ethernet top-of-rack
through can be
0 31
3
