LANCOM ES-2126+ and LANCOM ES-2126P+
Chapter 4: Operation of Web- based Management
4.9.10

Group

GVRP Group Information
To show the dynamic group member and their information.
4.10

STP

The Spanning Tree Protocol (STP) is a standardized method (IEEE 802.1D) for
avoiding loops in switched networks. When STP is enabled, ensure that only
one path is active between any two nodes on the network at a time. User can
enable Spanning Tree Protocol on switch's web management and then set up
other advanced items. We recommend that you enable STP on all switches to
ensure a single active path on the network.

Status

4.10.1
86
Parameter Description:
Current Dynamic Group Number: The number of GVRP group that are
created currently.
VID: VLAN identifier. When GVRP group creates, each dynamic VLAN
group owns its VID. Valid range is 1 ~ 4094.
Member Port: Those are the members belonging to the same dynamic
VLAN group.
Edit Administrative Control: When you create GVRP group, you can
use Administrative Control function to change Applicant Mode and
Registrar Mode of GVRP group member.
Refresh: Refresh function can help you to see current GVRP group sta-
tus.
Function name: STP Status
Function Description: In the Spanning Tree Status, user can read 12 para-
meters to know STP current status. The 12 parameters' description is listed
in the following table.
