. . . c o n n e c t i n g
y o u r
b u s i n e s s
LANCOM ES-2126+
LANCOM ES-2126P

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ES-2126+ and is the answer not in the manual?

Questions and answers

Related Manuals for Lancom ES-2126+

Summary of Contents for Lancom ES-2126+

  • Page 1 . . . c o n n e c t i n g y o u r b u s i n e s s LANCOM ES-2126+ LANCOM ES-2126P...
  • Page 2 LANCOM ES-2126+ LANCOM ES-2126P...
  • Page 3 The reproduction and distribution of the documentation and software supplied with this product and the use of its contents is subject to written authorization from LANCOM Systems. We reserve the right to make any alterations that arise as the result of technical development.
  • Page 4 The overall power output of 185 Watts from the PoE supply can be flexibly divided between the ports. The LANCOM switch can be managed with the clearly structured Webconfig and is supported by the LANCOM Management Tools (LANconfig and LANmonitor).
  • Page 5 The latest drivers, firmware, utilities and documentation are constantly available for download. In addition, LANCOM Support is available. For telephone numbers and contact addresses for LANCOM Support, please refer to the enc- losed leaflet or the LANCOM Systems Web site. Information symbols Very important instructions.

  • Page 6: Table Of Contents

    2.3 Status displays and interfaces 2.3.1 LEDs and buttons on the LANCOM ES-2126+ 2.3.2 LEDs and buttons on the LANCOM ES-2126P 2.3.3 Connectors on the LANCOM ES-2126+ and LANCOM ES- 2126P 2.4 Mounting and connecting up the LANCOM switch 2.5 Software installation 2.5.1 Starting the software setup...
  • Page 7 LANCOM ES-2126+ und LANCOM ES-2126P Contents 4 Operation of Web- based Management 4.1 Web Management Home Overview 4.1.1 The Information of Page Layout 4.2 System 4.2.1 System Information 4.2.2 IP Configuration 4.2.3 Time Configuration 4.2.4 Account Configuration 4.2.5 Management Security 4.2.6 Virtual Stack...
  • Page 8 LANCOM ES-2126+ und LANCOM ES-2126P Contents 4.15.2 Configuring the TACACS+ parameters 4.16 Alarm Configuration 4.16.1 Events 4.16.2 E-Mail 4.17 Security 4.18 Bandwidth Management 4.19 QoS (Quality of Service) Configuration 4.20 Diagnostics 4.20.1 Diagnostics 4.20.2 Loopback 4.20.3 Ping 4.20.4 Watchdog 4.21 TFTP Server 4.22 Log...
  • Page 9 LANCOM ES-2126+ und LANCOM ES-2126P Contents...

  • Page 10: Introduction

    The switch can be managed through RS-232 serial port via directly connec- tion, or through Ethernet port using Telnet or WEBconfig. Additionally, the LANCOM ES-2126+ models can be managed via SSH (Secure Shell) or WEBconfig with SSL-encryption. With the SNMP agent, the network adminis- trator can logon the switch to monitor, configure and control each port’s acti-...

  • Page 11: Key Features In The Device

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 1: Introduction Key Features in the Device QoS: Support Quality of Service by the IEEE 802.1P standard. There are two priority queue and packet transmission schedule using Weighted Round Robin (WRR). User-defined weight classification of packet priority can be based on either VLAN tag on packets or user-defined port priority.
  • Page 12 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 1: Introduction actions. TACACS+ is an alternative to other AAA protocols such as RADIUS. IGMP Snooping: Support IGMP version 2 (RFC 2236): The function IGMP snooping is used to establish the multicast groups to forward the multicast packet to the member ports, and, in nature, avoid wasting the bandwidth while IP mul- ticast packets are running over the network.

  • Page 13: Just What Can Your Lancom Switch Do

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 1: Introduction Just what can your LANCOM switch do? LANCOM ES- LANCOM ES- 2126+ 2126P Hardware ✔ ✔ Supports 24-port 10/100M TP ports with Nway and auto MDIX function ✔ ✔ 2 Gigabit dual media ports(TP/SFP) ✔...
  • Page 14 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 1: Introduction LANCOM ES- LANCOM ES- 2126+ 2126P ✔ ✔ 5 kinds of QoS, are as follows, MAC Priority, 802.1p Priority, IP TOS Pri- ority, and DiffServ DSCP Priority. ✔ ✔ WEBconfig and CLI management over telnet ✔...

  • Page 15: Installation

    Package content Before beginning with the installation, please check that nothing is missing from your package. Along with the LANCOM switch the box should contain the following accessories: LANCOM...

  • Page 16: Status Displays And Interfaces

    Meanings of the LEDs The following section describes the meaning of the LEDs. Please be aware that LANmonitor shows far more information about  the status of the LANCOM switch than the LEDs '→ Monitoring the LANCOM switch with LANmonitor'.

  • Page 17: Leds And Buttons On The Lancom Es-2126P

    10 Mbps or 100 Mbps mode is active. 2.3.2 LEDs and buttons on the LANCOM ES-2126P Located on the front of the device are light-emitting diodes (LEDs) that pro- vide information on device status, and also two buttons.
  • Page 18 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 2: Installation µ ¾ ³ » ¿ · º ¸ ¸ ³ CPU RUN Blinks green if the CPU is running without problem. · Power LED: Constant green when power is supplied to the device.

  • Page 19: Connectors On The Lancom Es-2126+ And Lancom Es

    Constant green when the optical port is active. Off when the TP port is active. Port 25 and 26 2.3.3 Connectors on the LANCOM ES-2126+ and LANCOM ES-2126P The following connectors are located on the rear of the device. ³...

  • Page 20: Software Installation

    Software installation The following section describes the installation of the Windows-compatible system software LANtools, as supplied. You may skip this section if you use your LANCOM switch exclusively  with computers running operating systems other than Windows. 2.5.1 Starting the software setup Place the product CD into your drive.

  • Page 21: Which Software Should I Install

    With LANmonitor you can use a Windows computer to monitor all of your LANCOM devices. This program displays all important status infor- mation for a LANCOM switch, such as link status or port PoE state. With Documentation you copy the documentation files onto your PC.

  • Page 22: Configuring And Monitoring The Lancom Switch

    Text-orientated configuration via a console (Command Line Interface – CLI): This method of configuration, which requires a program such as Tel- net, SSH (LANCOM ES-2126+ only) , Hyperterminal, or similar, can be con- ducted over a network connection or with a direct connection via serial interface (RS-232).
  • Page 23 The assigned IP address can only be determined by using the appropriate tools or via the DHCP server. If the DHCP server is a LANCOM device, the IP address of the LAN- COM switch can be read out from the DHCP table. If this is the case, the LANCOM switch can be accessed from any network computer that receives its IP address from the same DHCP server.

  • Page 24: Starting The Command Line Interface Over The Network

    3.1.2 Starting the Command Line Interface over the network If you know the device's IP address (see section above) and the LANCOM switch is accessible from your computer via the network, the you can use the command line interface via the network.

  • Page 25: Which Configuration Does The Device Use

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 3: Configuring and monitoring the LANCOM switch » Log on with user name and password (default: admin, admin). Which configuration does the device use? The switch supports four different configurations: The start configuration, the current working configuration, the user configuration and the default confi- guration.

  • Page 26: Save/Restore

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 3: Configuring and monitoring the LANCOM switch This is the default configuration and it cannot be altered. The web user interface has the following options to restore the switch to its default setting. With the function "restore default configuration included default IP address"...

  • Page 27: Config File

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 3: Configuring and monitoring the LANCOM switch Here you can save the current configuration to the flash memory as a user configuration. Restore default configuration (includes default IP address) Here you can reset the switch to its factory settings. The default configu- ration replaces the start configuration.

  • Page 28: Monitoring The Lancom Switch With Lanmonitor

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 3: Configuring and monitoring the LANCOM switch Export file path: Export start: You can export the start configuration from the flash memory. Export user conf.: You can export the user configuration from the flash memory.

  • Page 29: Port Poe Status

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 3: Configuring and monitoring the LANCOM switch Gray: The port is deactivated in the configuration Yellow: The port is activated in the configuration The right-hand icon shows the link state: Gray: No active network device is connected to the port...
  • Page 30 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 3: Configuring and monitoring the LANCOM switch Source Equipment (PSE) measures the power requirement of the device. Power requirements of the PDs are classified as follows: PoE class Power range default 0,44 W - 12.95 W optional 0,44 W - 3.84 W...

  • Page 31: 4 Operation Of Web-Based Management

    <Login> button. The login process now is completed. Alternatively you can login to the decive using an secure and encrypted con- nection via HTTPS and the Secure Sockets Layer SSL (LANCOM ES-2126+ only). The switch already contains the required certificate.

  • Page 32: Web Management Home Overview

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management trator’s identity, can only monitor the system. There are only a maximum of three users able to login simultaneously in the switch. To optimize the display effect, we recommend you use Microsoft IE 6.0 above or current FireFox and have the resolution 1024x768.
  • Page 33 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management information of a single port. When clicking the port on the front panel, an information window for the port will be pop out. The figure shows the basic information of the clicked port. With this, you’ll see the information about the port status, traffic status and bandwidth rating for egress and ingress respectively.

  • Page 34: System

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management System 4.2.1 System Information Function name: System Information Function Description: Shows the basic system information. Parameter Description: Model name: The model name of this device.

  • Page 35: Ip Configuration

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management System Description: As it is, this tells what this device is. Here, it is “24-Port 10/100BaseT/TX Managed PoE Switch”. Location: Basically, it is the location where this switch is put. User- defined.
  • Page 36 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Function name: IP Configuration Function Description: Set IP address, subnet mask, default gateway and DNS for the switch. Parameter Description: DHCP Setting: DHCP is the abbreviation of Dynamic Host Configura- tion Protocol.

  • Page 37: Time Configuration

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management networks, hence, subnet mask is introduced to solve this problem. Subnet mask uses some bits from host address and makes an IP address looked Network address, Subnet mask number and host address.
  • Page 38 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management 1305, has been adopted on the system is version 3 protocol. The switch pro- vides four built-in NTP server IP addresses resided in the Internet and an user- defined NTP server IP address.
  • Page 39 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management time since it passed over. And when the time passes over the ending time, the system time will be decreased one hour after one minute at the time since it passed over.

  • Page 40: Account Configuration

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Hour: Range is 0 ~ 23. Default: 0 4.2.4 Account Configuration In this function, only administrator can create, modify or delete the username and password. Administrator can modify other guest identities’ password wit- hout confirming the password but it is necessary to modify the administrator- equivalent identity.

  • Page 41: Management Security

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Password: guest 4.2.5 Management Security Through the management security configuration, the manager can do the strict setup to control the switch and limit the user to access this switch.
  • Page 42 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management ¿ When both “accept and deny” lists exist, then it will deny all connections, excluding the connection inside of the accepting range. ´ When both “accept and deny” lists exist, then it will deny all connections, excluding the connection inside of the accepting range and NOT inside of the denying range at the same time.
  • Page 43 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Parameter Description: Name: A name is composed of any letter (A-Z, a-z) and digit (0-9) with maximal 8 characters. VID: The switch supports two kinds of options for managed valid VLAN VID, including “Any”...

  • Page 44: Virtual Stack

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management while you select “Accept” action, you will have the authority to manage the switch. Edit/Create: A new entry of Management Security Configuration can be created after the parameters as mentioned above had been setup and then press <Edit/Create>...

  • Page 45: System Log

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management configure more than two devices as Master device, however, the Master device with the smaller MAC value will be the Master one. All of these 16 devices can become Master device and back up with each other .

  • Page 46: Port

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Display the order number that the trap happened. Time: Display the time that the trap happened. Desc: Displays a description event recorded in the System Log. Clear: Clear log data.
  • Page 47 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Function Description: It is used to set each port’s operation mode. The switch supports 3 parameters for each port. They are State, Speed/Duplex and Flow Control. Parameter Description: State: Set the communication capability of the port is Enabled or Disabled.

  • Page 48: Port Status

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management 4.3.2 Port Status The function Port Status gathers the information of all ports’ current status and reports it by the order of port number, media, link status, port state, Auto- Negotiation status, speed/duplex, Rx Pause and Tx Pause.
  • Page 49 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management State: Show that the communication function of the port is “Enabled” or “Disabled”. When it is enabled, traffic can be transmitted and received via this port. When it is disabled, no traffic can be transferred through this port.
  • Page 50 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Default: None. Parameter description of Port 25 and Port 26: Connector Type: Display the connector type, for instance, UTP, SC, ST, LC and so on. Fiber Type: Display the fiber mode, for instance, Multi-Mode, Single- Mode.

  • Page 51: Simple Counter

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Mon1(Bias) mA: Show the Bias current of module. Mon2(TX PWR): Show the transmit power of module. Mon3(RX PWR): Show the receiver power of module. 4.3.3 Simple Counter The function of Simple Counter collects any information and provides the counting about the traffic of the port, no matter the packet is good or bad.

  • Page 52: Detail Counter

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management 4.3.4 Detail Counter The function of Detail Counter collects any information and provides the counting about the traffic of the port, no matter the packet is good or bad.
  • Page 53 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Rx Multicast Packets: Show the counting number of the received mul- ticast packet. Rx Pause Packets: Show the counting number of the received pause packet. Tx Collisions: Number of collisions transmitting frames experienced.

  • Page 54: Poe

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Tx Pause Packets: Show the counting number of the transmitted pause packet. Rx FCS Errors: Number of bad FSC packets received. Rx Alignment Errors: Number of Alignment errors packets received.
  • Page 55 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Port No: Port number. Port On: Shows whether the port is supplying the power to the PD or not. AC Disconnect Port Off: Port is turned off due to the AC Disconnect function.
  • Page 56 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management once the power required by the PD excesses the Class, Short Circuit or over temperature occurs. Parameter Description: Status: Include “Normal” or “Active” two kinds of status. The former means the port is ready to link and supply the power to the PD at any time.

  • Page 57: Loop Detection

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Class: The Class of the PD linked to the port of the switch. Loop Detection The loop detection is used to detect the presence of traffic. When switch recei- ves packet's(looping detection frame) MAC address the same as oneself from port, show Loop detection happens.
  • Page 58 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Basically, it is passive except issuing the trap information. The switch supports a switch to turn on or off the SNMP agent. If you set the field SNMP “Enable”, SNMP agent will be started up.

  • Page 59: Dhcp Boot

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Default trap host IP address: 0.0.0.0 Default port number :162 Trap: In the switch, there are 6 trap hosts supported. Each of them has its own community name and IP address; is user-definable. To set up a trap host means to create a trap manager by assigning an IP address to host the trap message.

  • Page 60: Igmp Snooping

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management power and then reboot and recover. At this moment, a bunch of switch or other network device on the LAN will try its best to find the server to get the services or try to set up the predefined links, they will issue many broadcast packets in the network.
  • Page 61 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management The packets will be discarded by the IGMP Snooping if the user transmits mul- ticast packets to the multicast group that had not been built up in advance.
  • Page 62 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management VLAN ID: Shows VLAN ID for each multicast group. Member Port: Shows member ports that join each multicast group. Member port may be only or more than one.

  • Page 63: Vlan

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Edit: The existed entry also can be modified after pressing <Edit> but- ton. Delete: Remove the existed entry of allowed group configuration from the allowed group. VLAN The switch supports Tag-based VLAN (802.1q) and Port-based VLAN. Support 256 active VLANs and VLAN ID 1~4094.
  • Page 64 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management 1&2&3&4. If you are on the port 1, you can communicate with port 2&3&4. If you are on the port 5, then you cannot talk to them. Each port-based VLAN you built up must be assigned a group name.

  • Page 65: Tag-Based Group

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management 4.9.2 Tag-based Group Function name: Tag-based Group Configuration Function Description: It shows the information of existed Tag-based VLAN Groups. You can also easily create, edit and delete a Tag-based VLAN group by pressing <Add>, <Edit>...
  • Page 66 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management will be untagged. Finally, press the <Apply> button to have the setting taken effect. Delete Group: Just press the <Delete> button to remove the selected group entry from the Tag-based group table.

  • Page 67: Pvid

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management 4.9.3 PVID Function name: PVID Function Description: In PVID Setting, user can input VID number to each port. The range of VID number is from 1 to 4094. User also can choose ingress filtering rule (Rule 2) to each port.

  • Page 68: Port-Based Group

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management If the former is the case, then the packets with tagged or untagged will be processed. If the later is the case, only the packets carrying VLAN tag will be processed, the rest packets will be discarded.

  • Page 69: Mac Table

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Delete Group: Just press the <Delete> button to remove the selected group entry from the Port-based group table. Edit a group: Just select a group entry and press the <Edit> button, then you can modify a group‘s description and member set.
  • Page 70 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Parameter Description: Port: Select the port you would like to inquire. Search: Set up the MAC entry you would like to inquire. The default is ??-??-??-??-??-?? MAC: Display the MAC address of one entry you selected from the searched MAC entries table.
  • Page 71 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Aging Time: Delete a MAC address idling for a period of time from the MAC Table, which will not affect static MAC address. Range of MAC Address Aging Time is 10-1000000 seconds. The default Aging Time is 300 seconds.
  • Page 72 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Parameter Description: MAC: It is a six-byte long Ethernet hardware address and usually expressed by hex and separated by hyphens. For example, 00 – 40 - C7 - D6 – 00 - 01 VID: VLAN identifier.

  • Page 73: Gvrp Configuration

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Function name: MAC Alias Create/Edit or Delete Function Description: In the MAC Alias function, MAC Alias Add/Edit func- tion is used to let you add or modify an association between MAC address and a plain English name.
  • Page 74 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management In GVRP Configuration function folder, there are three functions supported, including GVRP Config, GVRP Counter and GVRP Group explained below. Function name: GVRP Config unction Description: In the function of GVRP Config, it is used to confi- gure each port’s GVRP operation mode, in which there are seven parame-...
  • Page 75 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Default Applicant Mode: The mode here means the type of partici- pant. There are two modes, normal participant and non-participant, provided for the user’s choice. Normal: It is Normal Participant. In this mode, the switch participates normally in GARP protocol exchanges.
  • Page 76 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Function Description: All GVRP counters are mainly divided into Received and Transmitted two categories to let you monitor the GVRP actions. Actually, they are GARP packets. Parameter Description:...
  • Page 77 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Transmitted: Total GVRP Packets: Total GARP BPDU is transmitted by the GVRP application. Invalid GVRP Packets: Number of invalid GARP BPDU is transmit- ted by the GVRP application.

  • Page 78: Stp Configuration

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management 4.12 STP Configuration The Spanning Tree Protocol (STP) is a standardized method (IEEE 802.1D) for avoiding loops in switched networks. When STP is enabled, ensure that only one path is active between any two nodes on the network at a time. User can enable Spanning Tree Protocol on switch’s web management and then set up...
  • Page 79 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Current Max. Age: Show the current root bridge maximum age time. Maximum age time is used to monitor if STP topology needs to change. When a bridge does not receive a hello message from root...

  • Page 80: Stp Configuration

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management STP Configuration 4.12.2 The STP, Spanning Tree Protocol, actually includes RSTP. In the Spanning Tree Configuration, there are six parameters open for the user to configure as user’s idea. Each parameter description is listed below.

  • Page 81: Stp Port Configuration

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management from Learning state moved to Forwarding state of a port in bridge. The forward delay time contains two states, Listening state to Learning state and Learning state to Forwarding state. It assumes that forward delay time is 15 seconds, then total forward delay time will be 30 seconds.
  • Page 82 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Port Status: It displays the current state of a port. We cannot manually set it because it displays the status only. There are three possible sta- tes. ( according to 802.1w specification) DISCARDING state indicates that this port can neither forward packets nor contribute learning knowledge.
  • Page 83 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Edge Ports will immediately transit to forwarding state and skip the listening and learning state because the edge ports cannot create bridging loops in the network. This will expedite the convergence.

  • Page 84: Trunking Configuration

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management ration is to make the port quickly get back to act as an RSTP port. Click <M Check> button to send a RSTP BPDU from the port you specified.
  • Page 85 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management The switch LACP does not support the followings: Link Aggregation across switches Aggregation with non-IEEE 802.3 MAC link Operating in half-duplex mode Aggregate the ports with different data rates ·...
  • Page 86 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Parameter Description: Method: This determines the method a port uses to aggregate with other ports. None: A port does not want to aggregate with any other port should choose this default setting.
  • Page 87 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Function name: Aggregator View Function Description: To display the current port trunking information from the aggregator point of view. Parameter Description: Aggregator: It shows the aggregator ID (from 1 to 26) of every port.
  • Page 88 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Function name: LACP Detail (LACP Aggregator Detailed Information) Function Description: Show the detailed information of the LACP trunking group. Parameter Description: Actor: The switch you are watching on.

  • Page 89: Configuration

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Default: DA and SA. 4.14 802.1x Configuration 802.1x port-based network access control provides a method to restrict users to access network resources via authenticating user’s information. This rest- ricts users from gaining access to the network resources through a 802.1x-...
  • Page 90 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management A port acting as an authenticator is thought to be two logical ports, a con- trolled port and an uncontrolled port. A controlled port can only pass the...
  • Page 91 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Supplicant PAE. In this case, PC A wants to access the services on device B and C, first, it must exchange the authentication message with the authenticator on the port it connected via EAPOL packet. The authenticator transfers the supplicant’s credentials to Authentication server for verification.
  • Page 92 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management ´ And next, the Supplicant replies an EAP-Response/Identity to the authen- ticator. The authenticator will embed the user ID into Radius-Access- Request command and send it to the authentication server for confirming its identity.
  • Page 93 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Only MultiHost 802.1X is the type of authentication supported in the switch. In this mode, for the devices connected to this port, once a supplicant is authorized, the devices connected to this port can access the network resource through this port.
  • Page 94 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Function Description: This function is used to configure the global para- meters for RADIUS authentication in 802.1x port security application. Parameter Description: Radius Server: RADIUS server IP address for authentication.
  • Page 95 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management 802.1x Mode: 802.1x operation mode. There are two options, inclu- ding Disable and Multi-host mode. Default is Disable. Disable: It will have the chosen port acting as a plain port, that is no 802.1x port access control works on the port.
  • Page 96 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management of 802.1X authenticator. The Port Status will show the following screen. Port Number:The port number to be chosen to show its 802.1X Port Status. The valid number is Port 1 – 26.
  • Page 97 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Period, reAuthEnabled, reAuthPeriod, max. Request, suppTimeout, serverTimeout and Controlled direction. Port Control: This is used to set the operation mode of authorization. There are three type of operation mode supported, ForceUnauthori- zed, ForceAuthorized, Auto.

  • Page 98: Tacacs

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management suppTimeout(1-65535 s): A timeout condition in the exchange bet- ween the authenticator and the supplicant. The valid range: 1 – 65535. Default: 30 seconds. serverTimeout(1-65535 s): A timeout condition in the exchange bet- ween the authenticator and the authentication server.

  • Page 99: Configuring The Tacacs+ Parameters

    The value 0.0.0.0 deactivates this entry. Secret key: The password for encrypting the communications between NAS and TACACS+ servers. The password must be entered identically into the LANCOM and the  TACACS+ server. We recommend that you do not operate TACACS+...
  • Page 100 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Authentication The device for configuration can be accessed via the serial interface (console), via the LAN with Telnet or SSH, or with a browser. Access authentication for each of these three access methods can be individually set up either to refer to the user accounts in the device itself, or to the the user accounts on the TACACS+ server.
  • Page 101 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Authorization State: Activates authorization via TACACS+ server. If TACACS+ authorization is activated, all authorization data is transmitted via TACACS+ protocol to the configured TACACS+ server. On the TACACS+...
  • Page 102 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Reboot Security SNMP System TACACS+ TFTP Time Trunk VLAN Virtual Stack. The arguments “show” and “set” can be permitted or restricted separately for each command. For the admin account all undefined commands must be permitted, ...

  • Page 103: Alarm Configuration

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Accounting State: Activates accounting via TACACS+ server. If TACACS+ accounting is activated, all accounting data is transmitted via TACACS+ protocol to the configured TACACS+ server. TACACS+ accounting will only activate if the defined TACACS+ server ...

  • Page 104: E-Mail

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management LACP: LACP Disabled, LACP Enabled, LACP Member Added, LACP Port Failure GVRP: GVRP Disabled, GVRP Enabled VLAN: Port-based VLAN Enabled, Tag-based VLAN Enabled Module Swap: Module Inserted, Module Removed, Dual Media Swap- PoE: PoE Failure 4.16.2...

  • Page 105: Security

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Email: Mail Server: the IP address of the server transferring your email. Username: your username on the mail server. Password: your password on the mail server. Email Address 1 – 6: email address that would like to receive the alarm message.
  • Page 106 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Function name: Function name: Isolated Group Function Description: Isolated Group function can let the port be indepen- dent of other ports in the Isolated group, and the communication is also forbidden between these ports.

  • Page 107: Bandwidth Management

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Function Description: The function of the Restricted Group can decide the direction of transmitting packets for the specific port. The packets recei- ved by the port with the “Ingress” mode of Restricted Group will be sent to the ports with the “Egress”...
  • Page 108 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Function Description: Ingress Bandwidth Setting function is used to set up the limit of Ingress bandwidth for each port. Parameter Description: Port No.: Choose the port that you would like this function to work on it.
  • Page 109 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Function Description: Egress Bandwidth Setting function is used to set up the limit of Egress bandwidth for each port. Parameter Description: Port No.: Choose the port that you would like this function to work on it.

  • Page 110: Qos (Quality Of Service) Configuration

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Parameter Description: Storm Type: Disable: Disable the function of the bandwidth storm control. Broadcast Storm Control: Enable the function of bandwidth storm control for broadcast packets. Multicast Storm Control: Enable the function of bandwidth storm control for multicast packets.
  • Page 111 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management bit SERVICE TYPE field that specifies how the datagram should be handled. The field could be divided into six subfields as follows, PRECEDENCE (3 bits), D-Type (Delay Priority, 1 bit ), T-Type (Throughput Priority, 1bit), R-Type (Reli- ability Priority, 1bit ), M-Type (Monetary Cost Priority, 1bit ), and UNUSED (1bit User can randomly control these fields to achieve some special QoS goals.
  • Page 112 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management · enable both VIP and DSCP Choose priorities of VIP and DSCP. » enable both TOS and DSCP Choose "DSCP". ¿ enable both VIP and DSCP Choose priorities of VIP and DSCP.
  • Page 113 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Weight (1~55): Over here, you can make an arrangement to Weight values of Queue 0 to Queue 3. The range of Weight you can set is 1~55. In default, the weight of Queue 0 is 1, the weight of Queue 1 is 2, the weight of Queue 2 is 4, and the weight of Queue 3 is 8.
  • Page 114 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Function name: 802.1p Setting Function Description: This function will affect the priority of VLAN tag. Based on priority of VLAN tag, it can arrange 0~8 priorities, priorities can map to 4 queues of the switch (queue 0~3) and possess different band- width distribution according to your weight setting.
  • Page 115 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Parameter Description: TOS Delay Priority Mapping: Each Priority can select any of Queue 0 ~ Queue 3. In Default, Priority 0 is mapping to Queue 0, Priority 1 is...
  • Page 116 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Parameter Description: TOS Throughput Priority Mapping: Each Priority can select any of Queue 0 ~ Queue 3. In Default, Priority 0 is mapping to Queue 0, Pri- ority 1 is mapping to Queue 0, Priority 2 is mapping to Queue 1, Pri-...
  • Page 117 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Parameter Description: TOS Reliability Priority Mapping: Each Priority can select any of Queue 0 ~ Queue 3. In Default, Priority 0 is mapping to Queue 0, Priority 1...
  • Page 118 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Parameter Description: TOS Monetary Cost Priority Mapping: Each Priority can select any of Queue 0 ~ Queue 3. In Default, Priority 0 is mapping to Queue 0, Pri-...

  • Page 119: Diagnostics

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Parameter Description: DSCP Priority Mapping: 64 kinds of priority traffic as mentioned above, user can set up any of Queue 0~3. In default, Priority 0~15 are mapping to Queue 0, Priority 16~31 are mapping to Queue 1, Priority 32~47 are mapping to Queue 0, Priority 48~63 are mapping to Queue 4.20...

  • Page 120: Loopback

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management 4.20.2 Loopback Function name: Loopback Test Function Description: In the Loopback Test function, there are two diffe- rent loopback tests. One is Internal Loopback Test and the other is Exter- nal Loopback Test.

  • Page 121: Ping

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management 4.20.3 Ping Function name: Ping Test Function Description: Ping Test function is a tool for detecting if the target device is alive or not through ICMP protocol which abounds with report messages.

  • Page 122: Tftp Server

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Time Gap: To support the time gap for ping test. Host To support to ping one host IP address. You need to configure one host IP address which you want to ping it.

  • Page 123: Log

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Parameter Description: Specify the IP address where the TFTP server loca- tes. Fill in the IP address of your TFTP server, then press <Apply> button to have the setting taken effect.

  • Page 124: Firmware Upgrade

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Events:Display the trap event name. Auto Upload Enable: Switch the enabled or disabled status of the auto upload function. Upload Log: Upload log data through tftp. Clear Log: Clear log data.

  • Page 125: Reboot

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Path and Filename: File path and filename stored the image file you want to upgrade. 4.24 Reboot We offer you many ways to reboot the switch, including power up, hardware reset and software reset.

  • Page 126: Logout

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 4: Operation of Web- based Management Logout 4.25 You can manually logout by performing Logout function. In the switch, it pro- vides another way to logout. You can configure it to logout automatically. Function name: Logout Function Description: The switch allows you to logout the system to pre- vent other users from the system without the permission.

  • Page 127: Operation Of Cli Management

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management 5 Operation of CLI Management CLI Management Refer to Chapter 2 for basic installation. The following description is the brief of the network connection. -- Locate the correct DB-9 null modem cable with female DB-9 connector.

  • Page 128: Commands Of Cli

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Fig. 4-1 Fig. 4-2 Commands of CLI Fig. 4-3...

  • Page 129: Global Commands Of Cli

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management 5.2.1 Global Commands of CLI Syntax: Description: Back to the top mode. When you enter this command, your current position would move to the top mode. If you use this command in the top mode, you are still in the position of the top mode.
  • Page 130 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management PSES-2126C(trunk)# exit PSES-2126C# help Syntax: help Description: To show available commands. Some commands are the combination of more than two words. When you enter this command, the CLI would show the complete commands.
  • Page 131 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management logout Logout the system save start Save as start config save user Save as user config restore default Restore default config restore user Restore user config PSES-2126C(ip)# history Syntax:...
  • Page 132 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management 9. events 10. end 11. ip 12. help 13. history PSES-2126C(ip)# history 3 Command history: 12. help 13. history 14. history 3 PSES-2126C(ip)# logout Syntax: logout Description: When you enter this command via Telnet connection, you would logout the system and disconnect.
  • Page 133 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management choose N or n, the IP address will keep the same one that you had saved before. If restoring default successfully, the CLI would prompt if reboot immediately or not. If you press Y or y, the system would reboot immediately;...
  • Page 134 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Restoring ... Restore User Configuration Successfully Press any key to reboot system. save start Syntax: save start Description: To save the current configuration as the start one. When you enter this command, the CLI would save your current configuration into the non- volatile FLASH.

  • Page 135: Local Commands Of Cli

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Saving user... Save Successfully PSES-2126C# 5.2.2 Local Commands of CLI Please note: to use one of the local commands, you first have to change to the corresponding configuration area, e.g. 802.1x <Enter> set mode 1.
  • Page 136 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management 1:set 802.1x to Multi-host mode Possible value: <port range> : 1 to 26 <mode>: 0 or 1 Example: PSES-2126C(802.1x)# set mode 2 1 set port- control Syntax: set port-control <port-range> <authorized>...
  • Page 137 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management <port range> : 1 to 26 <sec> : 0-65535, default is 60 Example: PSES-2126C(802.1x)# set quiet-period 2 30 set reAuthEnabled Syntax: set reAuthEnabled <port-range> <ebl> Description: A constant that define whether regular reauthentication will take place on this port.
  • Page 138 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Example: PSES-2126C(802.1x)# set reAuthMax 2 2 set reAuthPeriod Syntax: set reAuthPeriod <port-range> <sec> Description: A constant that defines a nonzero number of seconds between periodic reauthentication of the supplicant.
  • Page 139 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management set state Syntax: set state <ip> <port-number> <secret-key> Description: To configure the settings related with 802.1X Radius Server. Argument: <ip> : the IP address of Radius Server, and the IP format is xxx.xxx.xxx.xxx <port-number>...
  • Page 140 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management set txPeriod Syntax: set txPeriod <port-range> <sec> Description: A timer used by the Authenticator PAE state machine to determine when an EAPOL PDU is to be transmitted. Argument: <port range> : syntax 1,5-7, available from 1 to 26 <sec>...
  • Page 141 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Disable show parameter Syntax: show parameter Description: To display the parameter settings of each port. Argument: None. Possible value: None. Example: PSES-2126C(802.1x)# show parameter port 1) port control : Auto...
  • Page 142 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management PSES-2126C(802.1x)# show security Port Mode Status ====== ============ ============== Disable Multi-host Unauthorized Disable Disable Disable Disable show state Syntax: show state Description: To display the Radius server configuration. Argument: None.
  • Page 143 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management <name> : new account name Possible value: <name> : A string must be at least 5 character. Example: PSES-2126C(account)# add aaaaa Password: Confirm Password: PSES-2126C(account)# Syntax: del <name> Description: To delete an existing account.
  • Page 144 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Current username (aaaaa):bbbbb New password: Confirm password: Username changed successfully. Password changed successfully. show Syntax: show Description: To show system account, including account name and identity. Argument: None. Possible value: None.
  • Page 145 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management <#>: 1 to 6 Example: PSES-2126C(alarm-email)# del mail-address 2 del server-user Syntax: del server-user Description: To remove the server, user account and password. Argument: None. Possible value: None. Example:...
  • Page 146 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Argument: <ip>:email server ip address or domain name Possible value: None. Example: PSES-2126C(alarm-email)# set server 192.168.1.6 set user Syntax: set user <username> Description: To set up the account of the email server.
  • Page 147 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Email Address 2: Email Address 3: Email Address 4: Email Address 5: Email Address 6: <<events>> del all Syntax: del all <range> Description: To disable email, sms and trap of events.
  • Page 148 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management To disable the sms of the events. Argument: <range>:del the range of sms, syntax 1,5-7 Possible value: <range>: 1~22 Example: PSES-2126C(alarm-events)# del sms 1-3 del trap Syntax: del trap <range>...
  • Page 149 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Description: To enable the email of the events. Argument: <range>:set the range of email, syntax 1,5-7 Possible value: <range>: 1~22 Example: PSES-2126C(alarm-events)# set email 1-3 set sms Syntax: set sms <range>...
  • Page 150 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management show Description: The Show here is used to display the configuration of alarm event. Argument: None. Possible value: None. Example: PSES-2126C(alarm-events)# show Events Email SMS Trap ----------------------------------------- 1 Cold Start...
  • Page 151 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management 20 Module Removed 21 Moudle Media Swapped 22 PoE Failure show (alarm) Syntax: show Description: The Show for alarm here is used to display the configuration of Trap, SMS or E-mail.
  • Page 152 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Description: To delete sms server, user account and password. Argument: None. Possible value: None. Example: PSES-2126C(alarm-sms)# del server-user set phone- number Syntax: set phone-number <#> <phone-number> Description: To add sms phone number.
  • Page 153 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management set user Syntax: set user <username> Description: To set up user account and password of sms server. Argument: <username>: SMS server account Possible value: None. Example: PSES-2126C(alarm-sms)# set user ABC...
  • Page 154 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management autologout autologout Syntax: autologout <time> Description: To set up the timer of autologout. Argument: <time>: range 1 to 3600 seconds, 0 for autologout off, current setting is 180 seconds.
  • Page 155 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management set ingress-rate <range> <data_rate> Description: To set up the ingress-rate of the ports. Argument: <range>:syntax 1,5-7, available from 1 to 26 <data_rate>: 66-1024000(Kb). port 1-24: 66-102400(Kb); port 25-26: 66-1024000(Kb) Possible value: <range>: 1 to 26...
  • Page 156 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Description: To display all current settings of the bandwidth. Argument: None. Possible value: None. Example: PSES-2126C(bandwidth)# show Port Ingress Rate(Kb) Egress Rate(Kb) ====== ================== ================= 102400 102400 102400 102400...
  • Page 157 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Argument: None. Possible value: None. Example: PSES-2126C(config-file)# export start Export successful. export user- conf Syntax: Description: To run the export user-conf function. Argument: None. Possible value: None. Example: PSES-2126C(config-file)# export user-conf Export successful.
  • Page 158 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management To run the import user-conf function. Argument: None. Possible value: None. Example: PSES-2126C(config-file)# import user-conf Import successful. set export-path Syntax: Description: To set up the file path and filename that user would like to export.
  • Page 159 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Argument: None. Possible value: None. Example: PSES-2126C(config-file)# show TFTP Server IP Address: 192.168.3.111 Export Path and Filename: log/21511.txt Import Path and Filename: log/21511.txt dhcp- boot set dhcp- boot Syntax: Description: To set up the delay time for DHCP Boot.
  • Page 160 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Second : 30 PSES-2126C(dhcp-boot)# diag diag Syntax: diag Description: Diag is used to test whether EEPROM, UART, DRAM and Flash is normal or not. Argument: None. Possible value: None.
  • Page 161 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management External Loopback Test : Port 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 Fail...
  • Page 162 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Argument: None. Possible value: None. Example: PSES-2126C(firmware)# show TFTP Server IP Address: 192.168.3.111 Path and Filename : FEL2SW26_ES2126_v2.05.img upgrade Syntax: Description: To run the software upgrade function. Argument: None.
  • Page 163 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management enable Syntax: enable Description: To enable the gvrp function. Argument: None. Possible value: None. Example: PSES-2126C(gvrp)# enable group Syntax: group <group number> Description: To enter any of gvrp group for changing gvrp group setting. You can change the applicant or registrar mode of existing gvrp group per port.
  • Page 164 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management PSES-2126C(gvrp-group-2)# show GVRP group VID: 2 Port Applicant Registrar ---- --------------- --------- Non-Participant Normal Non-Participant Normal Non-Participant Normal Non-Participant Normal Non-Participant Normal Non-Participant Normal Normal Normal Normal Normal Normal...
  • Page 165 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Non-Participant Fixed Non-Participant Fixed Normal Fixed Normal Fixed Normal Fixed Normal Fixed Normal Normal Normal Normal Normal Normal Normal Normal Normal Normal set applicant Syntax: set applicant <range> <normal|non-participant>...
  • Page 166 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management To set default registrar mode for each port. Argument: <range>: port range, syntax 1,5-7, available from 1 to 26 <normal>: set registrar as normal mode <fixed>: set registrar as fixed mode <forbidden>: set registrar as forbidden mode...
  • Page 167 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management 1000 Normal Normal Enable 1000 Normal Normal Enable 1000 Normal Normal Enable 1000 Normal Normal Enable 1000 Normal Normal Enable 1000 Normal Normal Enable 1000 Normal Normal Enable 1000...
  • Page 168 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management set timer Syntax: set timer <range> <join> <leave> <leaveall> Description: To set gvrp join time, leave time, and leaveall time for each port. Argument: <range> : port range, syntax 1,5-7, available from 1 to 26 <join>: join timer, available from 20 to 100...
  • Page 169 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management ---- --------- ---------- ------------- -------------- - --------- ---------- 1000 Normal Normal Disable 1000 Normal Normal Disable 1000 Normal Normal Disable 1000 Normal Normal Disable 1000 Normal Normal Disable 1000...
  • Page 170 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Counter Name Received Transmitted -------------------- -------- ----------- Total GVRP Packets Invalid GVRP Packets ---- LeaveAll message JoinEmpty message JoinIn message LeaveEmpty message Empty message show group Syntax: show group Description: To show the gvrp group.
  • Page 171 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Argument: <name>: hostname, max. 40 characters. Possible value: <name>: hostname, max. 40 characters. Example: PSES-2126C# hostname Company Company# igmp- snooping add allowed- group Syntax: add allowed-group <ip-multicast> <vid> <port-range>...
  • Page 172 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Possible value: <index>: the index of the allowed-group. Example: PSES-2126C(igmp-snooping)# del allowed-group 1 set mode Syntax: Description: To set up the mode of IGMP Snooping. Argument: <status>: 0:disable, 1:active, 2:passive Possible value: <status>: 0,1or 2...
  • Page 173 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management To display IP multicast table. Argument: None. Possible value: None. Example: PSES-2126C(igmp-snooping)# show multicast IP Multicast: None disable dhcp Syntax: disable dhcp Description: To disable the DHCP function of the system.
  • Page 174 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management PSES-2126C(ip)# enable dhcp manual set dns Syntax: set dns <ip> Description: To set the IP address of DNS server. Argument: <ip> : dns ip address Possible value: <ip> : 168.95.1.1 Example: PSES-2126C(ip)# set dns 168.95.1.1...
  • Page 175 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management To display the system’s DHCP function state, IP address, subnet mask, default gateway, DNS mode, DNS server IP address and current IP address. Argument: None. Possible value: None. Example:...
  • Page 176 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Description: To disable the auto-upload function. Argument: None. Possible value: None. Example: PSES-2126C(log)# disable auto-upload enable auto- upload Syntax: enable auto-upload Description: To enable the auto-upload function. Argument: None.
  • Page 177 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Tftp Server : 0.0.0.0 Auto Upload : Disable 1) Wed Apr 13 12:13:27 2005 Link Up [Port 1] 2) Wed Apr 13 12:13:26 2005 Link Down [Port 1] 3) Wed Apr 13 11:58:31 2005 Login [admin]...
  • Page 178 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Possible value: <mac> : mac address Example: PSES-2126C(mac-table-alias)# del 00-44-33-44-55-44 Syntax: set <mac> <alias> Description: To set up the mac alias entry. Argument: <mac> : mac address, format: 00-02-03-04-05-06 <alias>...
  • Page 179 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management 00-33-03-04-05-06 ccc <<information>> search Syntax: search <port> <mac> <vid> Description: To look for the relative mac information in mac table. Argument: <port> : set up the range of the ports to search for, syntax 1,5-7, available form 1 to 26 <mac>...
  • Page 180 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management None. Example: PSES-2126C(mac-table-information)# show MAC Table List Alias MAC Address Port VID State ---------------- ----------------------- ---- ---- ----------------- 00-40-c7-d6-00-01 1 2 Static Forwarding ABC123 00-40-c7-d6-00-02 1 3 Static Filtering <<maintain>>...
  • Page 181 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management <port> : 1 to 24 <num>: 0 to 8191 Example: PSES-2126C(mac-table-maintain)# set learning 5 100 show Syntax: show Description: To display the settings of MAC table ageout time and the learning limit of each port.
  • Page 182 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management 8192 8192 <<static-mac>> Syntax: add <mac> <vid> <queue> <rule> <port> Description: To add the static mac entry. Argument: <mac>: mac address, format: 01-02-03-04-05-06 <vid>: VLAN id, from 1 to 4094 <queue>: which queue you want to set, from 0 to 3...
  • Page 183 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Possible value: <mac> : mac address Example: PSES-2126C(mac-table-static-mac)# del 00-02-03-04-05-06 show Syntax: show Description: To display static mac entry. Argument: None. Possible value: None. Example: PSES-2126C(mac-table-static-mac)# show VID Queue...
  • Page 184 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management PSES-2126C(management-add)# set This command will show exhaustive operating explanation for setting the management policy records. Argument: [<name> <value>] ACL entry name. [<vid> <value>] VLAN ID. [<ip> <value>] IP range.
  • Page 185 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management [#]: a specific or range management security entry(s) Possible value: None. Example: PSES-2126C(management)# show #: 1 Name : Tom VlanID : 2 IP : 192.168.1.30-192.168.1.80 Type : SNMP Action : Deny...
  • Page 186 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management [<vid> <value>] VLAN ID. [<ip> <value>] IP Range. [<port> <value>] Incoming port. [<type> <value>] Access type. <action> <value> a(ccept) or d(eny). Possible value: [<name> <value>] No default and it must be set.
  • Page 187 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management PSES-2126C(management)# show #: 1 Name : Tom VlanID : 2 IP : 192.168.1.30-192.168.1.80 Type : SNMP Action : Deny Port : 1,2 set priority Syntax: set priority <port-range> <priority>...
  • Page 188 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management PSES-2126C(poe)# set state 11 0 show Syntax: show Description: To display the PoE status. Argument: None. Possible value: None. Example: PSES-2126C(poe)# show Vmain : 48.3 V Imain : 0.0 A Pconsume : 0.0 W...
  • Page 189 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Power Management Port Off | X X X X X X X X X Port No | 13 14 15 16 17 18 19 20 21 22 23 24...
  • Page 190 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management 9 Normal Enable Normal 10 Normal Enable Normal 11 Normal Enable Normal 12 Normal Enable Normal 13 Normal Enable Normal 14 Normal Enable Normal 15 Normal Enable Normal 16 Normal Enable...
  • Page 191 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management disable state <range> Description: To disable the communication capability of the port. Argument: <range>: port range, syntax 1,5-7, available from 1 to 26 Possible value: <range>: 1 ~ 26...
  • Page 192 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management PSES-2126C(port)# set flow-control 3-6 symmetric set speed-duplex Syntax: set speed-duplex <range> <auto>|[<10|100|1000> <half|full>] Description: To set up the speed and duplex of all ports. Argument: <range>:port range, syntax 1,5-7, available from 1 to 26 <port-speed>:...
  • Page 193 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Example: PSES-2126C(port)# show conf show detail- counter Syntax: show detail-counter <#> Description: To display the detailed counting number of each port’s traffic. Argument: <#> : port, available from 1 to 26 Possible value: <#>:1 ~ 26...
  • Page 194 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Vendor Name : APAC Opto Vendor PN : KM28-C3S-TC-N Vendor Rev : 0000 Vendor SN : 5425011140 Date Code : 050530 Temperature : none : none Mon1 (Bias) mA...
  • Page 195 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Example: PSES-2126C(port)# show status Port Media Link State Auto Nego. Speed/Duplex Rx Pause Tx Pause ---- ----- ---- ------- ---------- ------------ ------ -- -------- Down Enable Enable ----/---- ----...
  • Page 196 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Description: To disable 802.1p qos. Argument: None. Possible value: None. Example: PSES-2126C(qos)# disable 1p disable dscp Syntax: disable dscp Description: To disable IP DSCP qos. Argument: None. Possible value: None.
  • Page 197 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management disable tos Description: To disable IP TOS qos. Argument: None. Possible value: None. Example: PSES-2126C(qos)# disable tos enable 1p Syntax: enable 1p Description: To enable 802.1p qos. Argument: None.
  • Page 198 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management enable qos Syntax: enable qos Description: To enable qos function. Argument: None. Possible value: None. Example: PSES-2126C(qos)# enable qos enable tos Syntax: enable tos Description: To enable IP TOS qos.
  • Page 199 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management You don't need to use all of queue, but must assign queue in order. Syntax: 1,2 or 2,5-7, available from 0 to 63. Possible value: <priority>: 0 to 63...
  • Page 200 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management <wrr|strict>: wrr or strict <wrr_0 to 3>: 1-55. Example: PSES-2126C(qos)# set sche wrr 1 2 8 16 set tos Syntax: <type_value> [<q0><priority>] [<q1><priority>] [<q2><priority>] [<q3><priority>] Description: To set IP tos qos weighting for 4 queues.
  • Page 201 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Argument: <port_range>: syntax 1,5-7, available from 1 to 26 <mode>: enable/disable vip port for each port. 1: enable. 0: disable. Possible value: <port_range>: 1 to 26 <mode>: 1 or 0...
  • Page 202 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management DiffServ Queue DiffServ Queue DiffServ Queue DiffServ Queue ---------- ------- ---------- ------- ---------- ----- -- ---------- ------...
  • Page 203 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management show port Syntax: show port Description: To show VIP port configuration. Argument: None. Possible value: None. Example: PSES-2126C(qos)# show port Port Based Priority ==================== Global QoS mode: Enable QoS Enable 802.1p Priority...
  • Page 204 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management show priority-tag Syntax: show priority-tag Description: To show 802.1p Qos configuration. Argument: None. Possible value: None. Example: PSES-2126C(qos)# show priority-tag 802.1p priority ==================== Global QoS mode: Enable QoS Enable 802.1p Priority...
  • Page 205 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management show tos Syntax: show tos Description: To show IP tos Qos configuration. Argument: None. Possible value: None. Example: PSES-2126C(qos)# show tos ip tos classification ==================== Global QoS mode: Enable QoS Disable 802.1p Priority...
  • Page 206 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management ---- ---- ---- ---- ---- ---- ---- ---- Queue 0 TOS type: Throughput Priority ---- ---- ---- ---- ---- ---- ---- ---- Queue 0 TOS type: Reliability Priority ---- ---- ---- ---- ---- ---- ---- ----...
  • Page 207 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Syntax: set <port> Description: To set up the function of the isolated group. Argument: <port> : isolated port; range syntax: 1,5-7, available from 0 to 26 set 0 as disabled Possible value: <port>:0 to 26...
  • Page 208 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management None. Possible value: None. Example: PSES-2126C(security-mirror)# disable enable Syntax: enable Description: To enable the function of mirror. Argument: None. Possible value: None. Example: PSES-2126C(security-mirror)# enable Syntax: set <spy> <ingress> <egress>...
  • Page 209 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management PSES-2126C(security-mirror)# set 1 4 2-3 show Syntax: show Description: To display the current setting status of mirror. Argument: None. Possible value: None. Example: PSES-2126C(security-mirror)# show Mirror: Monitoring Port :1...
  • Page 210 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management enable Syntax: enable set-community enable snmp Description: The Enable here is used for the activation snmp or set-community. Argument: None. Possible value: None. Example: PSES-2126C(snmp)# enable set-community PSES-2126C(snmp)# enable snmp Syntax: set get-community <community>...
  • Page 211 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management PSES-2126C(snmp)# set trap 1 192.168.1.1 162 public show Syntax: show Description: The Show here is to display the configuration of SNMP. Argument: None. Possible value: None. Example: PSES-2126C(snmp)# show...
  • Page 212 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management To force the port to transmit RST BPDUs. Argument: <range>: syntax 1,5-7, available from 1 to 26 Possible value: <range>: 1 to 26 Example: PSES-2126C(stp)# Mcheck 1-8 disable Syntax:...
  • Page 213 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Description: To set up the parameters of STP. Argument: <Bridge Priority>: priority must be a multiple of 4096,available from 0 to 61440. <Hello Time>: available from 1 to 10.
  • Page 214 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management <admin p2p>: auto / true / false Example: PSES-2126C(stp)# set port 1-16 0 128 yes auto set version Syntax: set version <stp|rstp> Description: To set up the version of STP.
  • Page 215 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management show port Syntax: show port Description: To display the port information of STP. Argument: None. Possible value: None. Example: PSES-2126C(stp)# show port Port Port Status Path Cost Priority Admin Edge Port...
  • Page 216 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management DISCARDING 20000 Auto DISCARDING 20000 Auto show status Syntax: show status Description: To display of the status of STP. Argument: None. Possible value: None. Example: PSES-2126C(stp)# show status STP Status :...
  • Page 217 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management set contact <contact> Description: To set the contact description of the switch. Argument: <contact>:string length up to 40 characters. Possible value: <contact>: A, b, c, d, ... ,z and 1, 2, 3, …. etc.
  • Page 218 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management show Syntax: show Description: To display the basic information of the switch. Argument: None. Possible value: None. Example: PSES-2126C(system)# show Model Name : PSES-2126C System Description : 24-Port 10/100BaseT/TX...
  • Page 219 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management show access Description: Shows the access configuration. Example: ES-2126+(tac-plus)# show access Access retry : 3 Access Login Login Primary Secondary ------- ------- --------- Console Local None Telnet TACACS Local...
  • Page 220 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Enables the TACACS+ functions for accounting, authorization and fallback to local authorization. Arguments: Accounting: enables the TACACS+ accounting. Authorization: enables the TACACS+ authorization. Fallback-author: enables the fallback to local authorization.
  • Page 221 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management set host Syntax: set host <#> <ip> Description: Sets the IP addresses for the first and secondary TACACS+ server. Arguments: #: Number from 1 (first TACACS+ server) to 2 (secondary TACACS+ server).
  • Page 222 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management value even on the secondary TACACS+ server, the secondary login method will be used. Arguments: retry: 1 to 3. Example: ES-2126+(tac-plus)# set retry 2 Sets the access retry value to “2”.
  • Page 223 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Example: ES-2126+(tac-plus)# set web-access 1 0 Sets the primary access mode for the login via web browser to TACACS+ and the secondary access mode to local user accounts. tftp...
  • Page 224 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management set daylightsaving <hr> <MM/DD/HH> <mm/dd/hh> Description: To set up the daylight saving. Argument: <hr> : daylight saving hour, range: -5 to +5 <MM> : daylight saving start Month (01-12) <DD>...
  • Page 225 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management <YYYY>: (2000-2036) <MM> : (01-12) <DD> : (01-31) <hh> : (00-23) <mm> : (00-59) <ss> : (00-59) Example: PSES-2126C(time)# set manual 2005/04/21 16:18:50 set ntp Syntax: set ntp <ip> <timezone>...
  • Page 226 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Current Time : Wed Apr 21 06:16:22 2005 NTP Server : 209.81.9.7 Timezone Day light Saving : 4 Hours Day light Saving Start: Mth: 2 Day: 20 Hour: 10...
  • Page 227 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Example: PSES-2126C(trunk)# set hash 2 set priority Syntax: set priority <range> Description: To set up the LACP system priority. Argument: <range>:available from 1 to 65535. Possible value: <range>:1 to 65535.
  • Page 228 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management <group>: 1-3. <active LACP>: active or passive Example: PSES-2126C(trunk)# set trunk 2-5 lacp 1 active show aggtr- view Syntax: show aggtr-view Description: To display the aggregator list. Argument: None.
  • Page 229 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Argument: None. Possible value: None. Example: PSES-2126C(trunk)# show lacp-config LACP System Priority : 33333 Hash Method : DA show lacp-detail Syntax: show lacp-detail <aggtr> Description: To display the detailed information of the LACP trunk group.
  • Page 230 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management ------ -------- ----------------- --------------- ---- ------------- show status Syntax: show status Description: Description: To display the aggregator status and the settings of each port. Argument: None. Possible value: None.
  • Page 231 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management None Active None Active None Active None Active None Active None Active None Active None Active None Active None Active None Active None Active None Active None Active None...
  • Page 232 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management To delete the tag-based VLAN group. Argument: <vid>: VLAN ID, available from 1 to 4094 Possible value: <vid>: 1 to 4094 Example: PSES-2126C(VLAN)# del tag-group 2 disable double-tag Syntax:...
  • Page 233 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management disable svl Description: To enable Independent VLAN Learning. Argument: None. Possible value: None. Example: PSES-2126C(VLAN)# disable svl disable symmetric Syntax: disable symmetric Description: To Not drop frames from the non-member port.
  • Page 234 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management enable drop- untag Syntax: enable drop-untag <port_range> Description: To enable drop-untag. Argument: <port_range>: which port(s) you want to drop untagged frames. Syntax: 1,5-7, available from 1 to 26 Possible value: <port_range>: 1 to 26...
  • Page 235 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Example: PSES-2126C(VLAN)# enable symmetric set mode Syntax: set mode <port|tag> Description: To switch VLAN mode between port-based and tag-based modes. Argument: <port|tag>: port or tag tag: set tag-based VLAN...
  • Page 236 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Argument: <port_range>: which port(s) you want to set PVID(s). Syntax 1,5-7, available from 1 to 26 <pvid>: which PVID you want to set, available from 1 to 4094 <default_priority>: which priority you want to set, available from 0 to 7 Possible value: <port_range>: 1 to 26...
  • Page 237 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management show config Description: To display the current VLAN mode, Symmetric VLAN, SVL and Double tag states. Argument: None. Possible value: None. Example: PSES-2126C(VLAN)# show config Current VLAN mode:Tag-based VLAN...
  • Page 238 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Member:1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 Untag :1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18...
  • Page 239 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management Disable Disable Disable Disable Disable Disable Disable Disable Disable Disable Disable Disable Disable Disable Disable Disable Disable Disable disable Syntax: disable Description: To disable the virtual stack. Argument: None.
  • Page 240 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management enable Syntax: enable Description: To enable the virtual stack. Argument: None. Possible value: None. Example: PSES-2126C(vs)# enable set gid Syntax: set gid <gid> Description: To set the group id.
  • Page 241 LANCOM ES-2126+ und LANCOM ES-2126P Chapter 5: Operation of CLI Management PSES-2126C(vs)# set role master show Syntax: show Description: To display the configuration of the virtual stack. Argument: None. Possible value: None. Example: PSES-2126C(vs)# show Virtual Stack Config: State : Enable...

  • Page 242: Appendix

    LANCOM ES-2126+ und LANCOM ES-2126P Chapter 6: Appendix 6 Appendix Performance data and specifications LANCOM ES-2126+ LANCOM ES-2126P Performance Switching technology Store and forward with latency less than 5 μs MAC addresses Support of max 8K MAC addresses Throughput max. 8.8 Gbps on the backplane...
  • Page 243 LANCOM ES-2126P CE conformity according to EN 55022, EN 55024, EN 60950 Environment Temperature range 0–40°C; humidity 5–90%; non-condensing Accessories 1000Base-SX SFP module, LANCOM SFP-SX-LC1, item no. 61556 1000Base-LX SFP module, LANCOM SFP-LX-LC1, item no. 61557 Service 5 years Support...

  • Page 244: Connector Wiring

    PoE/ -48 V PoE/ -48 V CE-declarations of conformity LANCOM Systems herewith declares that the devices of the type described in this documentation are in agreement with the basic requirements and other relevant regulations of the 1995/5/EC directive. The CE declarations of conformity for your device can be found on the relevant...
