LANCOM ES-2126+ and LANCOM ES-2126P+
Chapter 4: Operation of Web- based Management
4.17.2
Egress Bandwidth Setting
Egress Bandwidth Setting function is used to set up the limit of Egress band-
width for each port.
4.17.3
Storm Setting
With the storm control one can set a common limit for the permitted percen-
tage of the broadcast, multicast and unicast packets in comparison to the
whole data traffic. If this limit is reached, the data packets of the correspon-
ding type are discarded. The storm control can be activated separately for the
different packet types.
118
Parameter Description:
Port No.: Choose the port that you would like this function to work on
it. Valid range of the port is 1~26.
Rate: Set up the limit of Egress bandwidth for the port you choose.
Packet transmission will be delayed if the rate exceeds the value you
set up in Data Rate field. Traffic may be lost if egress buffers run full.
The format of the packet limits to unicast, broadcast and multicast.
Valid value of Port 1~24 ranges from 66~102400, and Port 25~26
ranges from 66~1024000 with the minimum unit of 1. Default value
of Port 1~24 is 102400 and Port 25~26 is 1024000.
