LANCOM ES-2126+ and LANCOM ES-2126P+
Chapter 4: Operation of Web- based Management
4.7.2

Allowed Group

The Allowed Group function allows the IGMP Snooping to set up the IP mul-
ticast table based on user's specific conditions. IGMP report packets that meet
the items you set up will be joined or formed the multicast group.
62
VLAN ID: Shows VLAN ID for each multicast group.
Member Port: Shows member ports that join each multicast group.
Member port may be only or more than one.
Parameter:
IP Range: The switch supports two kinds of options for managed valid
IP range, including "Any" and "Custom". Default is "Any". In case
that" Custom" had been chosen, you can assigned effective IP range.
The valid range is 224.0.0.0~239.255.255.255.
VID: The switch supports two kinds of options for managed valid
VLAN VID, including "Any" and "Custom". Default is "Any". When you
choose "Custom", you can fill in VID number. The valid VID range is
1~4094.
Port: The switch supports two kinds of options for managed valid port
range, including "Any" and "Custom". Default is "Any". You can select
the ports that you would like them to be worked and restricted in the
allowed group configuration if "Custom" had been chosen.
Add: A new entry of allowed group configuration can be created after
the parameters as mentioned above had been setup and then press
<Add> button.
