enable both VIP and DSCP
Choose priorities of VIP and DSCP.
»
enable both TOS and DSCP
Choose "DSCP".
¿
enable both VIP and DSCP
Choose priorities of VIP and DSCP.
´
enable both 802.1p and TOS
Choose "TOS".
²
enable both 802.1p and DSCP
Choose "DSCP".
¶
enable both 802.1p and DSCP and TOS
Choose "DSCP".
º
enable both 802.1p and DSCP and TOS and VIP
Choose priorities of VIP and DSCP.
VIP/DSCP > TOS > 802.1p (Final result)
4.18.1

QoS Global Setting

When you want to use QoS function, please enable QoS Mode in advance.
Then you can use MAC Priority, 802.1p Priority, IP TOS Priority, DiffServ DSCP
Priority, or VIP Port functions and take effect. In this function, you can Enable
QoS Mode. Choose any of Priority Control, such as 802.1p, TOS, DSCP. More-
over, you can select Scheduling Method of WRR (Weighted Round Robin) or
Strict Priority. Next, you can arrange Weight values for queue 0 to queue 3.
Parameter Description:
QoS Mode: You can Enable QoS Mode and let QoS function become
effective. Default is Disable.
Priority Control:Just tick the check box (ž) of 802.1P, TOS, or DSCP Qos
and click Apply button to be in operation.
Scheduling Method: There are two Scheduling Method, WRR and
Strict Priority. Default is WRR. After you choose any of Scheduling
Method, please click Apply button to be in operation.
