Dynacode IP Series
PS connection with internal power supply:
Connector CON3 (I/O)
(I/O, 16-pin)
+VCC
PS input
GND ext.
With external power supply Jumper 1 (3-4; 5-6) must be inserted.
Figure 14
PS connection (NPN/push-pull) with external power supply:
Connector CON2 (PS/encoder)
(Product sensor, 7-pin)
+Ub external
+Ub internal
PS input
GND internal
GND external
J2 is to be inserted into 2-3 (default)
Figure 15
PS connection (PNP/push-pull) with external power supply:
Connector CON2 (PS/encoder)
(Product sensor, 7-pin)
+Ub external 4
5
+Ub internal
PS input 6
1
GND internal
2
GND external
J2 is to be inserted into 2-3 (default)
Figure 16
08.16
11
x
2
x
1
x

7.5 External Power Supply

4
x
Prod.sensor
5
x
6
x
1
x
2
x
x
Prod.sensor
2
PNP
x
x
x
x
Operating Manual
(DC coupled)
Prod.sensor (PS)
(DC-isolated)
+Ub external
24VDC +/- 10%
1
NPN
GND external
(DC-isolated)
+Ub external
24VDC +/- 10%
GND external
Inputs and Outputs
25
