12.7 Ribbon Save (Continuous Mode)

Switch on the direct print module and the display shows the main
menu.
Press key to access the function menu.
Press key as long as you arrive the Ribbon Save menu.
Press key to select the menu.
Press keys and
Off No ribbon save.
Standard
Maximum ribbon save performance, i.e. with this
setting there is no loss of transfer ribbon (apart from
the safety distance of 1 mm, so the print fields are not
printed one into the other).
No settings are allowed with which the ribbon save no
more cannot be achieved. This particularly applies for
the print offset, which can only be adjusted now in the
valid range (see chapter 18.2, page 116).
Shift Layout data can be printed several times laterally
displaced. A maximum utilization of transfer ribbon can
be achieved (see chapter 18.3, page 119).
SaveStrt
No start signal loss, direct print module regulates the
ribbon save quality automatically according to
requirement.
Automatic layout ribbon save and field ribbon save,
each without feedback (see chapter 18.4, page 122).
Determination of max. print speed.
On the base of this value all necessary calculations e.g. feedback
distance and smallest possible print offset are being calculated.
Example
Speed = 400
Mode = Standard
However, if you print with a speed higher than 400 mm/s, then the
ribbon save result is decreased and/or the ribbon save can no longer
be executed, because the back-feed way was designed to 400 mm/s.
Please consider: if speed is set to 400 and only 300 mm/s are printed,
then a smaller number of cycles is reached as if speed is set to 300,
however a reserve of 100 mm/s is still available.
Therefore the speed value should be always set to the maximum print
speed. If the number of cycles is not sufficient, the rewind correction
should be applied.
Operating Manual
to select the desired ribbon save mode.
Very good ribbon save result between
50 mm/s and 400 mm/s.
