Dynacode IP Series
Back speed
Print offset
Print position
Layouts/cycle
08.16
Press key to arrive the next menu item.
Indication of back speed of the print mechanics after print end in
mm/s.
Each cycle of the machine consists of printing and return to the zero
point of machine. It is possible to set the print speed and back speed
separately. The setting range for the back speed is between 50 and
600 mm/s.
Because of this value you can select for low machine clock cycles an
operating method which saves the material and increases in this way
the life of the printhead.
Because of the mass moment of inertia it could be better to reduce the
speed at an installation position of the print unit at >30° horizontal.
Value range: 50 ... 600 mm/s.
Press key to arrive the next menu item.
Indication of distance of the layout (res. the first layout in case more
layouts per cycles are to be printed) to the zero point of machine.
Value range: 0 ... 93 mm
Default: 0 mm
Press key to arrive the next menu item.
Indication of start position of print carriage in mm.
Value range: 0 ... 93 mm
Default: 83 mm
Press key to arrive the next menu item.
Indication of the number of printed layouts per print start (cycle).
Value range: 1 ... 25.
