Function Menu
Resolution
Material speed
Operating mode
56
Press key to arrive the next menu item.
Encoder resolution / material feed per encoder rotation
Indication of resolution of used encoder and material feed per rotation
of encoder in mm. These settings help measuring the material speed.
The material feeding per encoder rotation corresponds for instance, in
a 1:1 translation between the encoder and the roller, to the roller
circumference.
Press key to arrive the next menu item.
Indication of material speed (only for reading purposes).

12.5 Maschinen Parameter (intermittierender Modus)

Switch on the direct print module and the display shows the main
menu.
Press key to access the function menu.
Press key as long as you arrive the Maschine Parameters
menu.
Press key to select the menu.
Single item A print order with a defined number of pieces is
processing
transferred. After the generating process the target
number and the actual number of pieces is shown in
the display. A cycle is started via signal input 1 or
with key
of pieces is increased by the number of printed
layouts. In case the target number of pieces is
reached the print order is finished and the display
shows again the main menu.
Continuous A print order is transferred. After the generating
mode
process the number of printed layouts is shown in
the display. A cycle is started via signal input 1 or
with key
printed layouts is increased. The print order is active
as long as it is terminated by the user or in case of
new data transmission.
Test mode
This operating mode corresponds to mode 2. After
the return of the print unit to the zero point of the
machine, however, internally a further cycle is
started (endurance test).
Direct start A print order is transferred. After termination of
generating process the print order is executed
without an external signal.
Operating Manual
Dynacode IP Series
. With each cycle the actual number
. With each cycle the number of
08.16
