Dynacode IP Series
Print resolution
Print speed
Continuous mode
Intermittent mode
Max. back speed
Print width
Print length
Continuous mode
Intermittent mode
Frame passage width
Printhead
Acoustic emission (measuring distance 1 m)
Average sound power level
Transfer ribbon
Ink
Max. roll diameter
Core diameter
Max. length
Max. width
Dimensions in mm (width x height x depth)
Print mechanics
without mounting frame
with mounting frame
Control unit
Weight
Print mechanics
Electronics with cable
Electronics
Processor
RAM
Slot
Battery
Warning signal
Interfaces
Serial
Ethernet
2 x USB Master
Connection values
Pneumatic connection
Nominal voltage
Nominal current
Fuse values
Operation data
Ingress Protection Rating
Temperature
Humidity
08.16
6

Technical Data

Dynacode IP53
300 dpi
50 ... 800 mm/s
50 ... 600 mm/s
600 mm/s intermittent mode only
53,3 mm
6000 mm
75 mm
customized
Corner Type
60 dB(A)
outside / inside (option)
98 mm
25,4 mm / 1"
900 m
55 mm
204 x 182 x 235
depending on passage width
310 x 165 x 350 - connecting cable set to the mechanics 2,5 m
9,5 kg
8 kg
High Speed 32 Bit
16 MB
Compact Flash Karte Typ I (inside the control unit)
for Real-Time clock (storage of data with shut-down)
accoustic signal when error
RS-232C (max. 115.200 Baud)
10/100 Base T, LPD, RawIP-Printing, DHCP, HTTP, FTP
connection for external USB keyboard and memory stick
min. 6 bar dry and free of oil
110 ... 230 V / 50 ... 60 Hz
230 V / 1,5 A − 110 V / 3 A
2x T4A 250 V
IP 65
5 ... 40 °C
max. 80% (non-condensing)
Operating Manual
Dynacode IP107
300 dpi
50 ... 600 mm/s
50 ... 600 mm/s
106,6 mm
3000 mm
75 mm
Corner Type
65 dB(A)
82 mm
25,4 mm / 1"
600 m
110 mm
204 x 182 x 290
11 kg
8 kg
Technical Data
Dynacode IP128
300 dpi
50 ... 450 mm/s
50 ... 600 mm/s
128 mm
3000 mm
75 mm
Corner Type
68 dB(A)
75 mm
25,4 mm / 1"
450 m
130 mm
204 x 182 x 310
11,7 kg
8 kg
19
