Ribbon Save (Intermittent Mode) - Carl Valentin Dynacode IP Series Operating Manual

Function Menu
Mode
60

12.8 Ribbon Save (Intermittent Mode)

Switch on the direct print module and the display shows the main
menu.
Press key to access the function menu.
Press key as long as you arrive the Ribbon Save menu.
Press key to select the menu.
Press keys and
Off No ribbon saving.
Standard
Maximum ribbon save performance, i.e. with this
setting there is no loss of transfer ribbon (apart from
the safety distance of 1 mm, so the print fields are not
printed one into the other).
No settings are allowed with which the ribbon save no
more cannot be achieved. This particularly applies for
the print offset, which can only be adjusted now in the
valid range (see chapter 18.5, page 123).
Shift Layout data can be printed several times laterally
displaced. A maximum utilisation of transfer ribbon can
be achieved (see chapter 18.6, page 124).
Operating Manual
to select the desired ribbon save mode.
Dynacode IP Series
08.16
