Dynacode IP Series
Protocol
Printhead resolution
Drive mapping
08.16

12.14 Emulation

Switch on the direct print module and the display shows the main
menu.
Press key to access the function menu.
Press key as long as you arrive the Emulation menu.
Press key to select the menu.
CVPL: Carl Valentin Programming Language
®
ZPL: Zebra Programming Language
Change between CVPL protocol and ZPL II
Press key to confirm the selection.
The direct print module performs a restart and ZPL II
transformed into CVPL commands internally by the direct print module
and then executed by the direct print module.
In menu Protocol, press key
®
At activated ZPL II emulation the printhead resolution of the emulated
direct print module must be set, e.g. 11.8 Dot/mm (= 300 dpi).
NOTICE!
If the printhead resolution of the Zebra
of the Valentin device, then the size of objects (e.g. texts,
graphics) complies not exactly.
Press key to arrive the next menu item.
®
The access to Zebra
B: CF card
R: RAM Disk (standard drive, if not indicated)
is rerouted to the corresponding Valentin drives
A: CF
R: RAM Disk
This can be necessary if the available space on the RAM disk (at
present. 512 KByte) is not sufficient or if bitmap fonts are downloaded
to the direct print module and be stored permanently.
NOTICE!
As the printer build-in fonts in Zebra
in Valentin devices, this can cause small differences in the text
image.
Operating Manual
®
to arrive the next menu item.
drives
®
Function Menu
protocol.
®
commands are
®
printer differs from that
printers are not available
