Dynacode IP Series
Speed
(intermittent mode)
Contrast
Ribbon control
X displacement
08.16

12.3 Print Settings

Switch on the direct print module and the display shows the main
menu.
Press key to access the function menu.
Press key to select the menu Print settings.
Indication of print speed in mm/s (see chapter Technical Data). The
print speed can be determined for each print order anew.
The setting of print speed affects also the test prints.
Value range: 50 ... 600 mm/s
Step size: 10 mm/s
Indication of value to set the print intensity when using different
materials, print speeds or printing contents.
Value range: 10% ...200 %.
Step size: 10%.
Press key to arrive the next menu item.
Examination if the transfer ribbon roll is to end or if the ribbon was torn
at the unwinding roll.
Off: The ribbon control is deselected, i.e. the direct print module
continues without an error message.
On: The ribbon control is selected, i.e. the current print order is
interrupted and an error message appears at the display.
Strong sensibility: The direct print module reacts immediately to the
end of the transfer ribbon.
Weak sensibility: The direct print module reacts at approx. 1/3 more
slowly to the end of the transfer ribbon.
Press key to arrive the next menu item.
Displacement of the complete print transverse to the paper direction.
The displacement is possible only up to the edges of the printing zone
and is determined by the width of the focal line in printhead.
Value range: −90.0 ...+90.0.
Operating Manual
Function Menu
53
