Dynacode II IP

Technical Data

Print resolution
Print speed
Continuous mode
Intermittent mode
Back speed
Print width
Max. print length
Continuous mode
Intermittent mode
Frame passage width
Printhead
Acoustic Emission (measuring distance 1 m)
Average sound pressure level
Transfer Ribbon
Ink
Max. roll diameter
Core diameter
Max. length
Max. width
Dimensions (width x height x depth)
Print mechanics
without mounting frame
with mounting frame
Control unit
Weight
Print mechanics
Electronics with cable
Electronics
Processor
RAM
Slot
Battery Battery cache
Warning signal
Interfaces
Serial
USB
Ethernet
USB Master
Connection Values
Pneumatic connection
Air consumption typical*
* hub 1,5 mm
150 cycle/min
6 bar operating pressure
Nominal voltage
Nominal current
Fuse values
80
Dynacode II IP53
300 dpi
50 ... 800 mm/s
50 ... 600 mm/s
intermittent mode only: max. 600 mm/s
53.3 mm
6000 mm
75 mm
customized
Corner Type
60 dB(A)
outside or inside (option)
98 mm
25.4 mm / 1"
900 m
55 mm
204 x 182 x 235 mm
depends on passage width
314 x 230 x 100 – w/o protective cover, w/o connecting cables
314 x 350 x 100 – with protective corer, w/o connecting cables
9.5 kg
7 kg – with protective cover, w/o connecting cables
High Speed 32 Bit
16 MB
Compact Flash card type I (inside of control unit)
for Real-Time clock (storage of data with shut-down)
accoustic signal when error
RS-232C (up to 115.200 Baud)
2.0 High Speed Slave
10/100 Base T, LPD, RawIP-Printing, DHCP, HTTP, FTP
connection for external USB keyboard and memory stick
6 bar dry and free of oil
150 ml/min
110 ... 230 V AC / 50 ... 60 Hz
110 V AC / 3 A – 230 V AC / 1,5 A
2x T4A 250 V
English
Dynacode II IP107
300 dpi
50 ... 600 mm/s
50 ... 600 mm/s
106.6 mm
3000 mm
75 mm
customized
Corner Type
65 dB(A)
outside or inside (option)
82 mm
25.4 mm / 1"
600 m
110 mm
204 x 182 x 290 mm
11 kg
300 ml/min
Dynacode II IP128
300 dpi
50 ... 450 mm/s
50 ... 600 mm/s
128 mm
3000 mm
75 mm
customized
Corner Type
68 dB(A)
outside or inside (option)
75 mm
25.4 mm / 1"
450 m
130 mm
204 x 182 x 310 mm
11.7 kg
300 ml/min
