Technical Data - Carl Valentin DYNACODE Operating Manual

Dynacode series
Print width
Frame passage width
Print length
Continuous mode
Intermittent mode
Resolution
Print speed
Continuous mode
Intermittent mode
Back speed
Printhead
Acoustic emission
Average sound pressure level
Built-in fonts
1D bar codes
2D bar codes
Composite bar codes
Interface
Transfer ribbon
Core diameter
Max. length
Max. width
Coating outside
Dimensions in mm (width x height x depth)
Print mechanics
without mounting frame
with mounting frame
Control unit
Weight
Print mechanics
Electronics (incl. cable)
Connection values
Pneumatic connection
Nominal voltage
Nominal current
Fuse values
Operating conditions
Temperature
Relative humidity
Technical modifications are subject to change.
10.15
3

Technical data

Dynacode 53
53,3 mm
customized
6000 mm
75 mm
300 dpi
50 ... 800 mm/s
50 ... 600 mm/s
only intermittent mode: max. 600 mm/s
Corner Type
Measuring dist. 1 m
60 dB(A)
8 vector fonts
6 bitmap fonts, 6 proportional fonts
font height: min. 1 mm - max. 99 mm
CODABAR, Code 128, Code 2/5 interleaved, Code 39, Code 39 ext.,
Code 93, EAN 13, EAN 8, EAN ADD ON, GS1-128, Identcode, ITF 14,
Leitcode, Pharmacode, PZN 7 Code, PZN 8 Code, UPC-A, UPC-E
Aztec Code, CODABLOCK F, DataMatrix, GS1 DataMatrix,
MAXICODE, PDF 417, QR Code
GS1 DataBar Expanded, GS1 DataBar Limited, GS1 DataBar
Omnidirectional, GS1 DataBar Stacked, GS1 DataBar Stacked
Omnidirectional, GS1 DataBar Truncated
serial: RS-232C (up to 115200 baud) - parallel: Centronics
USB: 1.1 - Ethernet: 10/100 Base-T
25,4 mm / 1"
900 m (Ø 98 mm)
55 mm
inside (option)
204 x 180 x 234
depends on passage width
240 x 125 x 332 - connecting cable to mechanics 2,5 m
9,5 kg
5,5 kg
min. 6 bar dry and free of oil
110 ... 230 V / 50 ... 60 Hz
230 V / 1,5 A − 110 V / 3 A
230 V / 2 AT − 110 V / 4 AT
5 ... 40 °C
max. 80% (non-condensing)
Operating manual
Dynacode 107
106,6 mm
3000 mm
75 mm
50 ... 600 mm/s
50 ... 600 mm/s
Measuring dist. 1 m
65 dB(A)
25,4 mm / 1"
600 m (Ø 82 mm)
110 mm
inside (option)
204 x 180 x 290
11 kg
5,5 kg
Technical data
Dynacode 128
128 mm
3000 mm
75 mm
50 ... 450 mm/s
50 ... 600 mm/s
Measuring dist. 1 m
68 dB(A)
25,4 mm / 1"
450 m (Ø 75 mm)
130 mm
inside (option)
204 x 180 x 312
11,7 kg
5,5 kg
17
