HELP MESSAGES

13 HELP MESSAGES
Code
H101 Exposure switch
H102
H105 Emergency stop
button
H142 Height movement
H144
H148
H149
H150
66 Planmeca ProMax 3D Plus & 3D Mid with ProTouch
The X-ray unit incorporates a self-checking feature that
monitors the operation of the unit. If the system detects an
operating error a help message (e.g. H101) appears on
the touch screen.
The X-ray unit will not accept any commands from the
user until the help message is cleared from the touch
screen. Clear the message by touching the green check
mark.
The following list shows, in numerical order, all the help
messages that can appear.
Explanation
The exposure button was released
before end of exposure.
The exposure button is stuck or the
cable is short circuited.
The emergency stop button has been
activated.
Height movement is not possible
because the stop plate at the bottom of
the column was activated.
Height movement is not possible
because one (or more) of the
positioning control buttons or the
positioning joystick is stuck.
Height movement is not possible. The
position of the patient support table is
too high.
Height movement was stopped
because the C-arm cannot be moved
lower.
Height movement was stopped
because the patient support table
cannot be moved lower.
Comments
Guide the patient away from the
X-ray unit before moving the
C-arm.
Press and hold down the
exposure button for the entire
duration of the exposure.
Release the exposure button.
If necessary, contact your service
technician to replace the
exposure switch.
All movements of the X-ray unit
are blocked, no radiation is
generated.
Guide the patient away from the
X-ray unit. Then release the
emergency stop button to resume
normal operation.
Clear any obstruction before
moving the column again.
Release the button / joystick.
Press the X-ray unit down button
to move the patient support table
down.
Clear any obstruction before
continuing.
Clear any obstruction before
continuing.
