Head support B: Attaching head band
Head band
Support bars
Attaching chin cup
Chin cup
Adapter
9.1.3
Preparing Planmeca Romexis
User's Manual (3D)
Large openings
Planmeca ProMax 3D Plus & 3D Mid with ProTouch 25
If you are using the head band, attach it to the support
bars as shown. The side with the large openings should
be against the patient's forehead.
Insert the chin cup into the adapter. Insert the adapter into
the holes in the middle of the patient support table.
First select the patient.
3D PATIENT EXPOSURE
