MAIN PARTS
X-ray unit up / down
Down
Positioning joystick
Image volume up / down
Down
Open / close temple supports
16 Planmeca ProMax 3D Plus & 3D Mid with ProTouch
NOTE If for some reason either of the buttons gets stuck
Up
NOTE Be careful that the X-ray unit does not hit the ceiling
NOTE Make sure that there is no object under the telescopic
NOTE The column movement stops automatically if the
NOTE When positioning wheelchair patients always first
Stop plate
Up
The X-ray unit up and down buttons are used to adjust the
X-ray unit to suit the height of the patient.
The X-ray unit moves slowly at first, then faster.
during operation, you can stop the up / down
movement by pressing any of the other control
buttons or the positioning joystick. This is a safety
measure that guarantees that the up / down movement
can be stopped in an emergency.
when you press the up button. The maximum height
can be adjusted to suit offices with low ceiling, contact
your service technician for help.
column when you press the down button. If something
is in danger of becoming trapped, release the button
immediately to stop the movement.
emergency stop plate at the bottom is pressed
upwards. Clear any obstruction before moving the
column again.
move the X-ray unit down before you position the
patient in the unit.
The positioning joystick is used for horizontal adjustment
of the image volume in 3D imaging. It is used when the
patient is positioned in the X-ray unit.
The image volume up and down buttons are used for
vertical adjustment of the image volume in 3D imaging.
The buttons are used when the patient is positioned in the
X-ray unit.
The X-ray unit moves slowly when you press the up /
down button. The height of the patient support table is not
changed, i.e. the patient remains in the same position.
Press the temple support button to open the temple
supports in 2D imaging. The temple supports can be
closed by pressing the temple support button again.
