Planmeca ProMax 3D Plus User Manual page 71

Code
H151 Line voltage
H152
H161 Temperature
H162
H163
H165
H166
H172 User related
messages
H175
H177
H178
H181
H182
H183
H184
H185
H186
H187
H189
H193
H195
User's Manual (3D)
Explanation
The line voltage was too low during
exposure.
The line voltage is too low.
The temperature of the tube head is too
high.
The temperature of the lift motor is too
high.
The temperature of the power supply
unit (PSU) is too high.
The temperature of the tube head is too
high for the selected exposure values.
The maximum tube head energy level
was exceeded.
The sensor is not attached properly to
the cephalostat.
PC program selection is in conflict with
the selected X-ray unit program.
Exposure is not possible with these
settings.
Exposure is not possible with these
settings.
The imaging process was cancelled in
Planmeca Romexis.
Timeout in image data transmission.
The attached sensor is not suitable for
the selected program.
Remove the 3D sensor.
The 3D sensor is not attached properly. Attach and / or lock the sensor in
No IP address defined for 3D sensor.
Problem during image data
transmission.
The screen was touched during
exposure.
The Y coordinate is out of limits.
The 3D Model programs must not be
used for patient imaging.
Planmeca ProMax 3D Plus & 3D Mid with ProTouch 67
HELP MESSAGES
Comments
Exposure was interrupted.
Contact your service technician
for help.
Exposure is not possible.
Contact your service technician
for help.
Wait for a few minutes for the
tube head to cool down.
Wait for a few minutes for the lift
motor to cool down.
Wait for a few minutes for the
power supply unit (PSU) to cool
down.
Wait for a few minutes for the
tube head to cool down.
Wait for a few minutes for the
tube head to cool down or use
lower exposure values.
Attach and / or lock the sensor in
position.
Select another exposure mode in
Planmeca Romexis.
Change the image volume
settings.
Change the settings.
Exposure was interrupted.
Contact your service technician
for help.
Change the sensor.
position.
Exposure was interrupted.
Contact your service technician
for help.
Exposure was interrupted.
Set the Y coordinate between 64-
72 mm.
Use the 3D Model programs for
taking exposures of impressions
or plaster casts only.
