3D PATIENT EXPOSURE
Detaching sensor from C-arm
22 Planmeca ProMax 3D Plus & 3D Mid with ProTouch
3. Push in the C-arm electrical connector button on the
other side. This will make the electrical connection
between the sensor and C-arm.
NOTE Do not remove the sensor during imaging process.
1. Push in the C-arm electrical connector. This will
disconnect the electrical connection between the
sensor and C-arm.
2. Turn the locking knob 180 degrees. This will release
the locking mechanism.
3. Carefully pull the sensor out.
User's Manual (3D)
