Example 3: Time-dependent Configurations (Day/Night Switching)
Configure the settings for all additional switching times on this week-
day.
This completes the configuration for the configuration switching times
for Monday.
Then configure the settings for the switching times for the other week-
days.
Note: If the same switching times are required for more than one
weekday, it is sufficient to set them up for only one day. The switching
times can be copied to other weekdays.
Only a few changes need to be entered. The configuration that was
last valid on the previous day is always transmitted to the next day.
Therefore, it is not necessary to activate a configuration at midnight if
Copying Switching Times
Copy the switching times for the first weekday
set to the week days with the same switching
times.
To do this, open the page displayed in the fig-
ure to the right.
Under "Source", select the configured week-
day from the list field.
Under "Add/Replace", activate action to be
performed.
Under "Target", activate the weekdays on
which the same switching times are required.
Then click "Execute" to apply the settings to
the PBX.
This completes the configuration for the con-
figuration switching times.
Checking Switching Times
Check the switching times that are configured
for the current week in your PBX.
To do this, open the page displayed in the fig-
ure to the right.
If a holiday has been configured for the cur-
rent week, the weekday in question is high-
lighted in colour. In addition, the changes
resulting from the holiday switching times
configured are displayed.
If the automatic configuration switching is
changed by a manual switchover, it is also
displayed.
36
the configuration had already been activated on the previous day or
also on other days in the past.
Exception: If the "normal" procedure is interrupted by special switch-
ing times/configurations on a holiday, the PBX resumes the "normal"
procedure on the day after the holiday.
Example: Outside of the holidays, each weekday starts and ends with
Configuration 2. If Configuration 3 is activated due to a holiday, it only
remains activated until midnight (unless, the next day is also a holi-
day). The next "normal" weekday starts again with Configuration 2.
Configuring the holidays is done separately in the holiday table on the
page COMset
instead of public holidays, you can also use this to enter company
holidays, for example. All entered and activated holidays are handled
the same way regarding the switching times.
The figure shows you the following page with the settings for
COMset Configurations Copy switching times
The figure shows you the following page with the settings for
COMset Configurations Overview switching times
COMpact 5010 VoIP/5020 VoIP - Firmware version 4.0 - Configuration Manual 06 08/11
Functions Calendar Holidays. In addition to or
Example 3 on page
Example 3 on page
34:
