SS- -8

TORQUE SPECIFICATION

Intake pipe x Intake manifold
Injection pump x Timing gear case
No.1 camshaft timing pulley x Camshaft
No.2 camshaft timing pulley x Injection pump drive gear
Idler pulley bolt x Timing gear case
Timing belt tensioner x Timing gear case
Injection pump drive gear x Injection pump
Idler gear x Timing gear case
Timing gear cover x Timing gear case
Crankshaft pulley x Crankshaft
Camshaft oil seal retainer x Cylinder head
Camshaft bearing cap x Cylinder head
Cylinder head x Cylinder block
Injection nozzle x Cylinder head
Nozzle leakage pipe x Injection nozzle
Water outlet x Cylinder head
Intake manifold x Cylinder head
Oil dipstick guide x Cylinder head
Injection pipe x Injection nozzle
Injection pipe x Injection pump
Oil nozzle x Cylinder block
Main bearing cap x Cylinder block
Connection rod cap x Connecting rod
Rear oil seal retainer x Cylinder block
Balance shaft x Cylinder block
Balance shaft x Cylinder block
Rear end plate x Cylinder block
Flywheel x Crankshaft
Accelerator cable bracket x Cylinder head
Front engine hanger x Cylinder head
LH engine mounting bracket x Cylinder block
RH engine mounting bracket x Cylinder block
SERVICE SPECIFICATIONS
Part tightened
- - ENGINE MECHANICAL
N∙m
12
21
98
13
35
13
64
19
13
363
9
18
1st 39
2nd Turn 90˚
3rd Turn 90˚
54
30
16
20
20
15
15
25
1st 49
2nd Turn 90˚
1st 29
2nd Turn 90˚
13
32
8
8
145
20
47
68
68
1KZ-TE Pages From Manual
TO MODEL INDEX
SS16K- -01
kgf∙cm ft∙lbf
120 9
210 15
1,000 72
130 9
350 25
130 9
650 47
195 14
130 9
3,700 268
90 78
185 13
400 29
540 40
300 22
165 12
200 14
200 14
150 11
150 11
260 19
500 36
300 22
130 9
320 23
85 74 in.∙lbf
85 74 in.∙lbf
1,480 107
204 15
460 34
693 50
693 50
CONTINUED
