Print Direction
Orientation Option
Option
Head First
Head First
Print Direction
Orientation Option
Option
Foot First
Foot First
Foot First
Foot First
The factory default is Head First when IGP/PGL or IGP/VGL is enabled.
The factory default is Foot First when PPI1 is enabled.

Tear-Strip Time

When using Tear-Off Media Handling, Tear-Strip Time specifies the number
of seconds after the buffer is empty that the printer will wait before it advances
media to the tear bar position.
The range is 1-60 seconds, and the factory default is 1 second.

Pre-Peel Mode

•
Disable.
•
Enable. When using Peel-Off Media Handling, enabling Pre-Peel Mode
adds a forward and reverse motion to each label prior to printing. The
added forward pre-peel motion temporarily breaks the die cut label from
the liner, and the reverse motion places the label back on the liner prior to
printing, peeling, or dispensing the label. Pre-Peel Mode is usually
enabled only when using die cut labels with an aggressive adhesive that
makes automatic label removal from the liner difficult.
The factory default is Disable.

Pre-Peel Adjust

Pre-Peel Adjust represents the selectable distance that the label advances
during Pre-Peel Mode. The Pre-Peel Adjust distance selected is automatically
used when Pre-Peel Mode is enabled.
The range is 0.00 to 2.00 inches in .01 inch increments.
The factory default is 1.00 inch.
MEDIA CONTROL Submenus
Table 3. Head First
Result in Active IGP Emulations
Inv. Portrait
Inv. Landscape
Table 4. Foot First
Portrait
Landscape
Inv. Portrait
Inv. Landscape
(IGP/PGL or IGP/VGL)
Inv. Portrait
Inv. Landscape
Result in Active IGP/PPI1
Emulation
Portrait
Inv. Landscape
Inv. Portrait
Landscape
105
