5. Attach Interface:
a. Parallel Interface
Attach a suitable parallel printer cable from the computer to the
Centronics/IEEE 1284 interface connector at the back of the printer.
Snap the bail locks to the Centronics connector to secure the
interface cable to the printer.
b. Serial Interface
Attach a suitable serial printer cable from the computer to the DB-25
RS-232 Serial interface connector at the back of the printer. For
additional information on serial cable wiring, refer to "Diagnostics And
Troubleshooting" on page 241.
NOTE: The printer supports simultaneous connection of the Parallel and
Serial interfaces using the Auto Switching feature. Auto Switching is
described on page 233.
Serial Connection
Debug Connection
Parallel Interface
