CONTAINERIZED KITCHEN (CK)
OPERATION UNDER USUAL CONDITIONS
2. Unbuckle the awning from both doors and lay it up out of the way.
3. Remove the awning support bar from the brackets on the doors. Slip the straps from the
generator, air conditioner, and exhaust fan ducts from the awning rod. Leave the loops in
the straps, and the ducts attached to the units.
4. Store the awning support bar on the floor just inside the mechanical room.
5. Stuff the generator and air conditioner ducts into the openings of the units so that they are
not in the way. Drape the hood exhaust duct behind the generator discharge hood.
6. Remove the two door braces and store them on the floor underneath the air conditioners.
Ensure that the generator exhaust pipe has completely cooled before
attempting to disassemble the elbow pipe.
7. Remove the generator exhaust elbow pipe by loosening the clamp and slipping the elbow
through the awning from above. Store it at the right end of the generator. Leave the clamp
attached to the exhaust pipe end at the ceiling of the mechanical room.
8. Unscrew the awning from the door frame. Fold it and pack it on top of the generator.
9. Retrieve the ground rod assembly, clean it, and store it in its brackets next to the Power
Entrance Panel.
10. If they were used, place the screw jack extension/base plates at the left end of the
generator. Strap them down with two short rubber straps.
11. Disconnect the MBU fuel line at the connection below the Power Entrance Panel. Remove
the fuel can adapter from the can, place it in its storage bag, and pack it on the floor to the
left of the generator. Put the cap on the fuel can and remove the can from the mechanical
room. Stow the strap in any convenient place in the mechanical room.
12. Disconnect the generator's auxiliary fuel line at the other fuel can. Remove the fuel can
adapter from the can, place it in its storage bag, and pack it on the floor to the left of the
generator. Put the cap on the fuel can.
13. Coil the generator's auxiliary fuel line and stow it on the floor to the left of the generator.
14. Disconnect the wing jacks from the platform. Remove the platform and slide it, with the
edge containing the jack brackets up, between the screw jack extension/base plates and the
front of the generator. Pack the platform railing next to the platform.
15. Place the long portions of two ratchet straps into the two loops located at the base of the
generator. Temporarily place the loose ends of the straps on top of the generator.
16. Place the three stair/ladders on their sides with their tops to the left.
17. Place the 6 water cans, on their sides, between the stair/ladder treads.
18. Strap the stair/ladders in place by bringing the two ratchet straps over them and securing
them to the rings on the floor. Tighten the straps securely.
TM 10-7360-226-13&P
WARNING
0006 00-35
0006 00
