CONTAINERIZED KITCHEN (CK)
GROUP 09 HAND SINK ASSEMBLY REPAIR PARTS
(1) (2) (3)
ITEM SMR
NO. CODE NSN
1 PBOZZ
2 PBOZZ
3 XDOZZ
4 PAOZZ
5 PAOZZ
6 PAOZZ
7 PAOZZ
8 PAOZZ
9 PAOZZ
10 PAOZZ
11 PAOZZ
12 PAOZZ
13 PAOZZ
TM 10-7360-226-13&P
(4) (5)
PART
CAGEC NUMBER
39428 22785T63
39428 22785T68
39428 23605K52
09BX1 2088-594-154
097M6 40905
39428 2773K1
86458 M-I-WH6U3SS
20247 LK-2490
0U5N7 47011050-2
7S077 B03
39428 6226T12
39428 6226T11
39428 66215T78
0041 00-3/4 Blank
(6)
DESCRIPTION AND USABLE ON
CODE (UOC)
GROUP 09 HAND SINK ASSEMBLY
FIGURE 19 HAND SINK ASSEMBLY
CASTER, SWIVEL...................................................2
CASTER, SWIVEL, WITH BRAKE...........................2
SINK, HAND ........................................................... 1
PUMP, WATER ...................................................... 1
ASSEMBLY, POWER CABLE ................................ 2
DISPENSER, SOAP ............................................... 1
HEATER, WATER .................................................. 1
FAUCET, LAUNDRY, HOSE THREADED .............. 1
HOSE ASSEMBLY, INTERNAL DRAIN .................. 1
. GASKET, BUNA N................................................ 2
HOSE, WATER SUPPLY, 50-FT ............................ 1
HOSE, WATER SUPPLY, 25-FT ............................ 2
. WASHER, HOSE.................................................. 3
END OF FIGURE
0041 00
(7)
QTY
