CONTAINERIZED KITCHEN (CK)
UNIT MAINTENANCE PROCEDURES
Air conditioner – Unit 2
(Top Air Conditioner)
GROUND
UNUSED
CONDENSER BLOWER HIGH
CONDENSER BLOWER LOW
EVAPORATOR BLOWER HIGH
EVAPORATOR BLOWER LOW
COMPRESSOR 2
COMPRESSOR 1
12 VDC
UNUSED
Generator Set:
Refer to the troubleshooting procedures in TM 9-6115-642-24 to test the generator set.
REPLACE
Before servicing any component of the mechanical room, turn OFF and
tag or lock the required circuit breaker on the Power Distribution Panel.
Ensure all power is off to the component being serviced.
Power Entrance Panel: See WP 0026 00.
MBU Converter: Unplug the converter from its 115 VAC receptacle. Disconnect the 24 VDC
output power connectors. Remove the mounting hardware and replace the converter. Reinstall
hardware and connectors.
receptacle.
TM 10-7360-226-13&P
Figure 3. Air Conditioner Terminal Boards.
WARNING
Plug the converter power cable into the designated 115 VAC
0018 00-4
Air conditioner – Unit 1
(Bottom Air Conditioner)
GROUND
HEATER RELAY
CONDENSER BLOWER HIGH
CONDENSER BLOWER LOW
EVAPORATOR BLOWER HIGH
EVAPORATOR BLOWER LOW
COMPRESSOR 2
COMPRESSOR 1
12 VDC
UNUSED
0018 00
