CONTAINERIZED KITCHEN (CK)
DESCRIPTION OF OPERATOR CONTROLS AND INDICATORS
Mobile Warming Cabinet
The controls and indicators for the mobile warming cabinet (Figure 9) are located at the bottom
front of the unit and include the following:
•
Power switch (1): ON/OFF rocker switch turns the cabinet on and off.
•
Temperature control knob (2): Adjusts cabinet temperature setting.
•
Digital thermometer (3): Shows cabinet temperature (ºF)
•
Yellow indicator lamp (4): Lights when the heating element is on.
•
Red indicator lamp (5): Lights when the power is on.
1
ON
POWER
TM 10-7360-226-13&P
OFF
Figure 8. Cook Center Ventilation Control Switch.
2
5
Figure 9. Mobile Warming Cabinet Controls.
0005 00-9
FAN CONTROL
ON
3
THERMOMETER
4
O
F
0005 00
