TM 10-7360-226-13&P
CONTAINERIZED KITCHEN (CK) 0002 00
EQUIPMENT DESCRIPTION AND DATA
Tray Pack Heater
The CK includes a modified tray pack heater which is positioned to the left of the dual oven
assembly. The heater connects to the fuel and power lines on the back of the oven base.
Generator
A MEP-803A Tactical Quiet Generator (TQG) is located in the mechanical room, separate from
the cooking and serving areas. The generator's controls and indicators are accessible through
a door in the oven side of the mechanical room wall. Access to the generator for routine
maintenance is through a second door in the mechanical room wall, next to the cook center, and
through the exterior doors of the mechanical room. Refer to TM 9-6115-642-10 for more
information about the generator.
Power Entrance Panel and External Power
The CK can be powered by an external source via the Power Entrance Panel (PEP), located
next to the generator. This panel is a "waterfall" type that allows easy strain relief for the power
cable and connector. External power can be provided from a 120/208 volt, 50/60 Hz, 60 amp,
5-wire, 3-phase source. The power is connected through a box-mounted receptacle with flange
ring. A grounding terminal below the receptacle provides a connection for earth ground.
Lighting
Nine dual-tube, fluorescent fixtures provide the CK's interior lighting. Six provide white light for
normal operations and three have red filters to provide blackout lighting. The normal and
blackout lights are located as shown in Figure 13. Four of the fixtures are permanently mounted
in the core of the kitchen. The rest are removable and are divided between the two wing
sections. The removable fixtures attach to the wing arch supports and are removed for packout.
The white light fixture nearest the personnel access door contains a rechargeable nickel-
cadmium battery and circuitry to provide emergency lighting. If power to the CK is lost, this
fixture will operate for at least 90 minutes, providing light for personnel to evacuate the kitchen.
It can also be used to provide lighting during kitchen setup, until electrical power is connected.
The battery automatically recharges when power is connected to the kitchen. A test switch on
the fixture allows for testing operation of the emergency light feature.
0002 00-12
