CONTAINERIZED KITCHEN (CK)
GROUP 12 ELECTRICAL SYSTEM REPAIR PARTS
(1) (2) (3)
ITEM SMR
NO. CODE NSN
1 PAOZZ 5930-01-302-9739
2 PAOZZ 5930-01-367-5513
3 PAOZZ 5930-01-291-5467
4 PAOZZ 6210-01-172-5978
5 PAOZZ 5930-01-306-9740
6 PAOZZ 5930-01-174-8604
7 PAOZZ 5920-01-289-0884
8 PAOZZ
9 PAOZZ
10 PAOZZ
TM 10-7360-226-13&P
(4) (5)
PART
CAGEC NUMBER
0ET52 ZB2BA2
52090 ZB2BW33
52090 ZB2BW061
37833 ZB2BV05
37833 ZB2BT4
37833 ZB2BZ104
52090 ZB2BZ102
097M6 HBL22SP
097M6 HBL11SP
097M6 SSB1
0044 00-7
(6)
DESCRIPTION AND USABLE ON
CODE (UOC)
GROUP 12 ELECTRICAL SYSTEM
FIGURE 24 MAIN CONTROL PANEL
PUSH BUTTON, MOMENTARY ..............................1
PUSH BUTTON, ILLUMINATED, GREEN ...............2
CONTACT BLOCK, LIGHT MODULE ..................... 2
LIGHT, PILOT, AMBER .......................................... 2
PUSH BUTTON, RED, 40 MM, MAINTAINED ........ 1
CONTACT BLOCK, 2 N.C. CIRCUITS.................... 2
CONTACT BLOCK, 1 N.C. CIRCUIT ...................... 1
SWITCH, TOGGLE, DPDT, SPADE TERMINAL..... 1
SWITCH, TOGGLE, SPST, SPADE TERMINAL ..... 2
BOOT, SWITCH ..................................................... 3
END OF FIGURE
0044 00
(7)
QTY
