CONTAINERIZED KITCHEN (CK)
MAINTENANCE ALLOCATION CHART (MAC)
The "L" maintenance level is not included in column (4) of the MAC.
Functions to this level are identified by a work time figure in the "H"
column of column (4), and an associated reference code is used in the
REMARKS column (6). This code is keyed to the remarks and the SRA
complete repair application is explained there.
Column (5) – Tools and Equipment Reference Code. Column (5) specifies, by code, those
common tool sets (not individual tools), common Test, Measurement and Diagnostic Equipment
(TMDE), and special tools, special TMDE and special support equipment required to perform
the designated function. Codes are keyed to the entries in the tools and test equipment table.
Column (6) – Remarks Code.
alphabetical order, which is keyed to the remarks table entries.
Explanation of Columns in the Tools and Test Equipment Requirements
Column (1) – Tool or Test Equipment Reference Code. The tool or test equipment reference
code correlates with a code used in column (5) of the MAC.
Column (2) – Maintenance Level. The lowest level of maintenance authorized to use the tool or
test equipment.
Column (3) – Nomenclature. Name or identification of the tool or test equipment.
Column (4) – National Stock Number (NSN). The NSN of the tool or test equipment.
Column (5) – Tool Number. The manufacturer's part number, model number, or type number.
Explanation of Columns in the Remarks
Column (1) – Remarks Code. The code recorded in column (6) of the MAC.
Column (2) – Remarks. This column lists information pertinent to the maintenance function
being performed as indicated in the MAC.
TM 10-7360-226-13&P
NOTE
When applicable, this column contains a letter code, in
0032 00-4
0032 00
