CONTAINERIZED KITCHEN (CK)
TROUBLESHOOTING PROCEDURES (MODERN BURNER UNIT)
Table 1. Troubleshooting Procedures (Modern Burner Unit) – Continued
Malfunction
MBU shuts down during
operation
MBU fails to fuel
END OF WORK PACKAGE
TM 10-7360-226-13&P
Test or Inspection
MBU is in cook center
MBU is in oven assembly or tray pack
heater
No power at the unit
MBU power is on
No power to the unit
MBU has power but air compressor
cannot be heard
MBU power is on and air compressor
is running
0011 00-2
Corrective Action
Start right-side MBU first
Check/connect fuel connection at
the base of the mechanical room
wall
Refer to TM 10-7310-281-13&P
for additional troubleshooting
guidance for the MBU
Notify unit maintenance
See "MBU does not start"
Check fuel level light on MBU.
Refuel if necessary
Refer to TM 10-7310-281-13&P
for additional troubleshooting
guidance for the MBU
Notify unit maintenance
See "MBU does not start"
Refer to TM 10-7310-281-13&P
for additional troubleshooting
guidance for the MBU
Notify unit maintenance
NOTE: Refueling can take up to
4 minutes for a single MBU, and
even longer when more than one
is refueling at a time.
Ensure that the fuel line to the fuel
can is connected, can contains
fuel, and valve on fuel can adapter
is open
Ensure that all hoses are free of
leaks and fittings are tight
Refer to TM 10-7310-281-13&P
for additional troubleshooting
guidance for the MBU
Notify unit maintenance
0011 00
