CONTAINERIZED KITCHEN (CK)
OPERATION UNDER USUAL CONDITIONS
Referring to Figure 16, pack out the cook center as follows:
1. Pack the MBUs, griddle and grease pan in place.
2. Place the moving blanket over the griddle. Place the cook pot cradle adapters on the
blanket and fold the blanket over them.
3. Remove the drawer assemblies from the tables and stow them in the oven base. Place two
tables, with the legs folded, on the griddle. Place the tables so that their legs are down.
4. Retrieve the light storage box and remove any items stored inside. Unplug and take down
the removable light fixtures and place them in the box. Place the griddle splash guards
inside the box, on top of the fixtures.
The packed light storage box weighs approximately 100 lbs (45.4 kg).
Three persons must carry the box, lifting with legs not back, to prevent
injury.
5. Place the light storage box on top of the tables. Center the box on the tables.
6. Place two insulated food containers on the light storage box. Center the containers on the
box.
7. Place one ratchet tie-down strap over all of the above items. Attach the strap end to the tie-
down provision at the mechanical room end of the cook center, and the ratchet end to the
tie-down provision at the center of the cook center. Tighten the strap securely.
8. Pack the steam table and adapter top in place.
9. Place two tables, with the drawers removed and the legs folded, on the steam table and
adapter top. Stack the tables with their legs down.
10. Place three insulated food containers on the tables. Center the containers on the tables.
11. Place one ratchet tie-down strap over all of the above items. Attach the strap end to the tie-
down provision at the center of the cook center, and the ratchet end to the tie-down
provision at the right end of the cook center. Tighten the strap securely.
12. Place the lids on each of the four roasting pans. Place one pan in each of the four leftmost
compartments in the base assembly.
13. Place one pot cradle in each of the two rightmost compartments.
Tray Pack Heater
1. Pack the MBU in place. Disconnect the fuel and power lines, coil them, and pack them in
the bottom of the oven assembly. Ensure the fuel line dust plug is in place.
2. Unplug the heater fan power cable from the appliance control box and remove the heater
fan assembly from the back of the tray pack heater. If the tray pack heater must be drained,
temporarily set the fan assembly aside in a convenient location.
assembly inside the tray pack heater.
TM 10-7360-226-13&P
WARNING
0006 00-29
0006 00
Otherwise, pack the
