CONTAINERIZED KITCHEN (CK)
OPERATION UNDER USUAL CONDITIONS
7. Uncoil the water heater and water pump power cables from the back of the sink assembly
and temporarily drape them across the top of the assembly.
8. Roll up the window flap behind the sink location and secure it with the strap provided.
9. Position the sink assembly in its operational position and lock the front casters.
10. If it will not be needed to fill the steam table or tray pack heater, repack the 25-ft water
supply hose on the bottom shelf of the sink assembly.
11. Unstrap the mobile warming cabinet and move it to its operational position in the food
preparation wing, against the positioning rail on the floor. Place it as tightly in the corner as
possible and lock the front casters. Connect its power cord to the marked receptacle on the
ceiling raceway in the center core of the kitchen.
12. Unstrap and move the dual oven assembly to approximately its operational location in the
corner of the food preparation wing. Retrieve the chimney pipe from its storage location in
one of the drawer assemblies in the oven base and attach it to the outlet of the oven fan.
Orient the pipe so its outlet points downward.
13. Carefully guiding the chimney pipe through the opening in the wall, locate the oven
assembly against the positioning rail on the floor. Lock the front corner casters.
14. Uncoil the fuel line on right side of the oven assembly. Lead it along the floor against the
end wall, remove the dust caps, and attach it to the fuel supply fitting at the base of the
mechanical room wall.
15. Uncoil the longer of the two power cables on the left side of the oven assembly. Lead it up
the arch to its marked receptacle on the ceiling raceway. Plug in the cable and secure it to
the arch using the hook and loop ties provided.
16. Retrieve the appliance control box from its storage location in one of the drawer assemblies.
Hang it from the horizontal spacer bar just to the right of the center arch. Lead the power
cable up along the arch to its marked receptacle on the ceiling raceway. Plug in the cable
and secure it to the arch using the hook and loop ties provided.
17. Verify that the four switches on the appliance control box are OFF. Plug the power cables
for the water pump, water heater, and oven fan into their respective outlets on the bottom of
the box.
Ensure that no power cables are touching the tray pack heater or the
oven. They could become damaged and result in a fire or shock hazard.
18. Secure the excess lengths of cable between the fabric and the spacer bar.
19. Unstrap and remove the burner rack and base rack from on top of the tray pack heater.
Place them in a convenient location the serving wing.
20. Roll up the window flap next to the oven assembly and fasten it in place with the strap
provided.
21. Unstrap and move the tray pack heater to near its operational location next to the ovens.
TM 10-7360-226-13&P
CAUTION
0006 00-19
0006 00
