CONTAINERIZED KITCHEN (CK)
OPERATION UNDER USUAL CONDITIONS
DO NOT use one of the water supply hoses to drain the tray pack heater.
They are for potable water use and could become contaminated.
3. If the tray pack heater must be drained, roll it to the area of the personnel access door, open
its drain valve, and drain the water into the floor drain. Close the valve when draining is
complete. Pack the heater fan assembly inside the tray pack heater.
4. If necessary, disconnect the external drain hose and drain it. Tightly coil the hose and pack
it on the lower shelf of the sink assembly.
5. Position the tray pack heater as shown earlier in Figure 15, with its back to the mechanical
room wall.
6. Place two ratchet straps over the tray pack heater, running from the loops on the
mechanical room wall down to the tie-down provisions in the floor. Tighten the straps
securely.
7. Place the base rack inside the burner rack and set both on top of the tray pack heater.
Strap them down with two long rubber straps. Hook the straps under the edges of the tray
pack heater's base.
Dual Oven Assembly
1. Leave the MBUs in place with their fuel and power lines connected.
2. Unplug the 24 VDC power cable from the ceiling raceway. Coil the cable, along with the fuel
line and power cable to the tray pack heater, and pack them between the left MBU and the
left side of the oven base.
3. Disconnect the fuel line from its outlet at the mechanical room wall and install the dust plugs.
Coil the hose and pack it between the right MBU and the right side of the oven base.
4. Unplug the oven fan power cable from the appliance control box. Unplug the box's power
cable from the ceiling raceway, coil it, and place the box in one of the drawer assemblies.
5. Pull the oven assembly away from the fabric wall far enough to remove the chimney pipe.
Remove the pipe and store it on one of the drawer assemblies.
6. Position the oven assembly as shown earlier in Figure 15, with its back toward the cook
center, and strap it down with two ratchet straps from side to side. Run the straps under the
oven fan assembly.
Refrigerators
1. Place four insulated food transporters in each refrigerator, one on each shelf.
2. Strap the containers to the shelves using one short rubber strap over each container, placed
from back to front.
3. Unplug the refrigerators and temporarily move them to the serving wing while completing
packout and closure of the food preparation wing.
TM 10-7360-226-13&P
WARNING
0006 00-30
0006 00
