Changing the topcoat in the topcoat station

This section describes the three steps of changing the topcoat material:
•
•
User's Guide for the ImageCard® IV Printer
3
Figure 4-10: Replace the overlay cartridge
Lower the overlay cartridge into the printer (step 1 in
supply material passes between the heated roller and the platen roller. Turn the
supply knobs if needed to take up slack so the material does not wrinkle as the
cartridge is pushed in place.
Press down to seat the overlay cartridge in the printer.
If the cartridge becomes stuck part of the way into the station, turn the supply and
take-up knobs clockwise
Press the cartridge lock to secure the overlay cartridge in the printer (step 2 in
Figure 4-10).
Move the supply tracker toward the full supply roll until it rests on the supply roll
(step 3 in Figure 4-10).
i
If the supply tracker does not have a handle, it will move into position
automatically.
E
If you use an adjustable overlay cartridge, follow the steps provided with the
cartridge to produce a laminate patch placement that meets specifications.
Close the cover of the printer and press down to latch it. If the printer has a lock,
lock the printer.
Remove the topcoat cartridge
Load topcoat in the cartridge
1
2
1
iciv035u
slightly so the spindle ribs fit between the spool ribs.
♦
4-13
Figure 4-10). Make sure the
