B-16
Overlay cartridge
i
Three models of overlay cartridge are available. Order the cartridge that matches the
one you currently use.
•
If your printer has both topcoat and overlay stations, you must have specific
cartridges for topcoat and laminate (overlay). The cartridges are not
interchangeable.
Cartridge lock
Metal
Plastic
Cartridge lock
Figure B-10: Overlay cartridge, part number 557322-003
Figure B-11: Overlay cartridge, part number 551215-001
If your service provider advises you to use an adjustable overlay cartridge, you
can order a replacement adjustable overlay cartridge. The part number for the
Part number
557322-003
551215-001
iciv104u
User's Guide for the ImageCard® IV Printer
Serial numbers
0992 and lower
0993 and higher
