Two models of topcoat cartridge are available. Order the cartridge that matches the
one you currently use.
User's Guide for the ImageCard® IV Printer
adjustable overlay cartridge kit is 553402-001. Follow instructions provided with
the cartridge to use it.
Adjustment Knob
Figure B-12: Adjustable overlay cartridge
If your printer has both topcoat and overlay stations, you must have specific
cartridges for topcoat and laminate (overlay). The cartridges are not
interchangeable.
Cartridge lock
Metal
Plastic
Cartridge lock
Figure B-13: Topcoat cartridge, part number 557322-004
Clip
Part number
557322-004
551215-002
B-17
Serial numbers
0992 and lower
0993 and higher
