C-6
4
5
Set the serial port on Windows XP
1
2
3
4
Figure C-3: Settings dialog box
Choose the following settings:
Setting Value
Baud rate 9600
Data bits 8
Parity None
Stop bits 1
Flow control None
When the settings are correct, click OK to save settings and close the dialog box.
From the Start menu, choose Settings and then Control Panel.
From the Control Panel, choose the System icon.
Choose the Hardware tab, and then choose the Device Manager button.
Press the "+" next to Ports and double click the Communications Port to open the
Communications Port Properties dialog box.
♦
User's Guide for the ImageCard® IV Printer
