Replacing The Topcoat Cartridge - DataCard ImageCard IV User Manual

4-16
8
9
10 Wind the supply material in front of the guides and around the take-up spool (step
11 Use the label to secure the supply material on the take-up spool. Press the label
12 Pick up the topcoat cartridge and turn it over. Turn the topcoat take-up knob
The topcoat cartridge is ready to be replaced in the printer.

Replacing the topcoat cartridge

When replacing the topcoat cartridge, begin with the top cover open and a loaded
topcoat cartridge. Make sure the topcoat cartridge has been removed from the printer.
Replace the topcoat cartridge
i
1
1
4
Figure 4-12: Load topcoat in the cartridge
Make sure the ribs inside the spool align with the grooves in the spool holder.
Press on the spool and turn the supply roll slightly (if needed) until the spool fully
covers the spool holder ribs.
Lift the label on the supply roll and unroll about 8 inches from the supply roll.
3 in Figure 4-12). Make sure that the material will wind counterclockwise
onto the spool to secure the supply material (step 4 in
clockwise to remove any slack in the supply material.
Make sure the supply tracker is out of the way when you replace the topcoat
cartridge.
When the top cover opens, the interlock switch removes power to the motors
!
and fans. Power is removed from the heater in the topcoat (and overlay)
station. The topcoat (and overlay) station remains HOT.
Hold the topcoat cartridge over the topcoat station.
2
3
iciv150u
Figure
♦
User's Guide for the ImageCard® IV Printer
Loading supplies
.
4-12).
