Periodical check
1.1.4 Pick-up Roller / Paper Take-up Roller / Separation Roller
[2]
[3]
[4]
1.1.5

Registration Roller

[2]
[2]
[1]
[5]
[3]
bizhub C350 Field Service Ver.1.0 Mar. 2004
A. Cleaning procedure
[1]
1. Open the Paper Take-up Section
2. Wet a cloth with alcohol, and use it to
4582fs2523c0
A. Cleaning procedure
1. Open the Paper Take-up Section
2. Remove four screws [2] from the
4582fs2512c0
3. Remove the Wire Harness Saddle
[4]
4582fs2513c0
4. Wet a cloth with alcohol, and use it to
[6]
4582fs2514c0
2-4
Cover [1].
wipe up the Pick-up Roller [2], Paper
Take-up Roller [3] and Separation
Roller [4].
Cover [1].
Registration Roller Cover.
[4] and the screw [5] from the Regis-
tration/Timing Sensor mounting plate
[3].
wipe up the Registration Roller [6].
