Printer 4-Color: 94-Mm-Pitch Uneven Image - Konica Minolta Bizhub C350 Service Manual

Image quality problem
4.3.40

Printer 4-Color: 94-mm-pitch uneven image

A. Typical Faulty Images
4036fs4055c0
B. Troubleshooting Procedure
Step Section
Imaging Unit
1
Image Transfer
2
Belt Unit
Image Transfer
3
Roller Unit
bizhub C350 Field Service Ver. 2.0 April 2004
94 mm
Check Item
The surface of the PC Drum is
scratched.
The Image Transfer Belt Unit
drive gear is intact.
Image Transfer Roller is dam-
aged.
4-100
94 mm
4036fs4056c0
Result
YES Change Imaging Unit.
NO Correct.
Change Image Transfer Belt Unit.
YES Change Image Transfer Roller
Unit.
94 mm
4036fs4057c0
Action
