Trouble code
2.3

Solution

2.3.1

C0990:LCT Elevator Motor Failure

A. Detection timing
Malfunction code
The Elevator Motor Pulse Sensor (PC10-LCT) cannot detect both edges of H/L
C0990 even after the set period of time has elapsed while the Elevator Motor (M5-LCT) is
turning backward/forward (raise/lower).
B. Action
Elevator Motor (M5-LCT)
Elevator Motor Pulse Sensor (PC10-LCT)
Step
Check the motor and sensor connectors
1 for proper connection, and correct as
necessary.
Check the connector of motor for proper
2 drive coupling, and correct as neces-
sary.
3 PC10-LCT I/O, sensor check
4 M5-LCT operation check
5 PWB-H LCT replacement
6 PWB-C1 LCT replacement
Relevant electrical parts
Action
4-6
bizhub C350 Field Service Ver.1.0 Mar. 2004
Description
Interface Board (PWB-H LCT)
Main Control Board (PWB-C1 LCT)
WIRING DIAGRAM
Control signal
-
-
PWB-C1 LCT PJ3C1 LCT-5
PWB-C1 LCT
PJ4C1 LCT-7,6
-
-
Location
(Electrical compo-
nents)
-
-
F-2
H-2
F-6
E-8
