bizhub C350 Field Service Ver.2.0 April 2004
1.5.17

Cleaning of the Area around the Waste Toner Collecting Port

1.5.18

Replacing Ozone Filter

1.5.19

Cleaning of the Comb Electrode

1. Open the Rear Left Cover.
2. Remove the Waste Toner Bottle [1].
[1]
4036fs2045c1
3. Wipe the areas around the Waste
4036fs2509c0
1. Holding onto the hook, remove the
[1]
2. Remove the Paper Dust Remover.
☞ 2-16
3. Select "Tech. Rep. Mode"
4036fs2510c0
1. Open the Front Door.
2. Clean the Comb Electrode by mov-
NOTE
• Move the Comb Electrode Cleaning
[1]
4036fs2511c0
2-21
Periodical check
Toner Collecting Port clean of spilled
toner and dirt using a soft cloth
dampened with water or alcohol.
Ozone Filter [1].
→
"Counter" "Life" and clear the
count of "Paper Powder Filter/Ozone
Filter."
ing the Comb Electrode Cleaning
Lever [1] In and Out several times.
Lever slowly forward and backward
until it stops.
→
