Setting Up a Switch

After creating a switch, use the System Setup Wizard to configure the
following essential operation and management parameters:
SNMP settings for monitoring of the switch by 3WXM
VLANs
RADIUS servers and server groups
Wireless services
Auto-DAP profile settings
The SNMP security level and enabled version configured with this wizard
apply to all SNMP notification targets. However, the security model,
community string, and access type apply only to the notification target
3WXM Services.
To set up a switch
1 Select the Configuration tool bar option.
2 In the Organizer panel, select the WX switch.
3 In the Task List panel, select System Setup.
The System Setup wizard appears.
4 Read the first page, then click Next.
5 Optionally, create a static route, or click Next to skip this step.
a Select a static route to edit or click Create to create one.
To configure a default route, select Default Route and go to step b.
Otherwise, in the Destination IP Address box, type the destination IP
address and subnet mask in classless interdomain routing (CIDR)
notation (for example, 10.10.0.0/16).
b In the Gateway box, type the IP address of the default router
(gateway) that the route uses.
c In the Metric box, specify the cost for using the route (0 to
2,147,483,647). Lower-cost routes are preferred. The default is 1.
6 Click OK.
7 Configure SNMP settings:
